ArduCAM IMX519 Autofocus Camera - 16MP IMX519 camera module for Raspberry Pi
ID: 1178690
5906623404544
zł143.43
Tax included
zł116.61 tax excl.
Camera module with IMX519 sensor dedicated to Raspberry Pi minicomputers. It uses a 16 MP matrix and allows you to record video in resolutions of 1080p@30fps. ArduCAM B0371
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Module with IMX519 sensor dedicated to Raspberry Pi minicomputers. It uses a 16 MP matrix and allows you to record video in 1080p@30fps resolution. The camera is equipped with autofocus and has an integrated IR filter. It communicates via the MIPI CSI interface and works with the Raspberry Pi OS system using the V4L2 driver. The set includes a cable and an acrylic housing.
Features
- Sensor type: 16MP IMX519
- Pixel Size: 1.22um x 1.22um
- Optical Size: 1/2.534"
- Active pixels: 4656H × 3496V
- EFL: 4.28mm
- FoV: 80°
- Autofocus
- IR sensitivity: integrated IR filter
- Frame rate: 1920×1080@30 fps, 1280×720@60fps
- Sensor output format: RAW10/8, COMP8
- Interface type: MIPI CSI
- Acrylic housing
- Cable length: 150 mm
- Dimensions: 40 x 40 mm
Kit contains
- ArduCAM IMX519 Autofocus Camera
- FPC tape 15-pin 150 mm
- FPC tape 22-pin 150 mm
1178690
Data sheet
- Resolution
- 16 Mpx
- Interface
- MIPI CSI-2
- Sensor
- IMX519
- IR filter
- Yes
- Lens assembly
- none
