ArduCAM 8MP IMX219 Auto Focus Camera - camera with 8MP IMX219 sensor for Raspberry Pi
ID: 1195254
5902186307933
zł101.61
Tax included
zł82.61 tax excl.
This Raspberry Pi-compatible camera offers automatic and manual focus control via Python scripts and the OpenCV library. Equipped with an 8MP Sony IMX219 sensor and a wide 77.6° field of view, it's ideal for drones, robotics, surveillance systems, and medicine. Its compact design and easy setup make it ideal for both hobbyists and professionals. ArduCAM B0393
Description
The ArduCAM 8MP IMX219 with Auto Focus is an advanced camera module designed for single-board computers like the Raspberry Pi 4B, 3B+, Zero, and Zero 2W. Unlike standard fixed-focus camera modules, this model features a remotely controlled auto focus lens, which can be precisely adjusted via software. This gives users full control over image sharpness, greatly enhancing flexibility for both professional and hobbyist applications.
The module supports both automatic and manual focus control using simple Python scripts compatible with the OpenCV library. It uses the reliable Sony IMX219 sensor with an 8 MP resolution, providing excellent image and video quality. The camera is designed for easy setup and operation, even for beginners. With its wide 77.6° field of view and 2.8 mm focal length, it is well-suited for projects such as drones, autonomous robots, surveillance systems, and medical imaging. The compact board size and low power consumption make it ideal for embedded applications.
Features
- Sensor: Sony IMX219, 8MP, 1/4"
- Photo resolution: 3280 × 2464 pixels
- Video modes: 1080p47, 1640 × 1232p41, 640 × 480p206
- Sensor dimensions: 3.68 × 2.76 mm (4.6 mm diagonal)
- Pixel size: 1.12 µm × 1.12 µm
- Lens type: Programmable autofocus
- Focal length: 2.8 mm
- Aperture: F2.2
- Field of view: 77.6° (D), 65° (H), 51° (V)
- Focus range: from 80 mm to infinity
- IR-cut filter: Built-in (visible light only)
- Compatibility: Raspberry Pi 4B, 3B+, 3B, 2B, Zero, Zero 2W
- Estimated power consumption: up to 300 mA
- Board dimensions: 25 × 24 mm
Kit contains
- ArduCAM 8MP IMX219 camera module with autofocus
- 15 cm FPC cable (22-22pin)
- 15 cm FPC cable (15-22pin)
1195254
Data sheet
- Resolution
- 8MPx
- Interface
- CSI
- Sensor
- Sony IMX219
- IR filter
- Yes
- Lens assembly
- none
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
