Raspberry Pi HQ Camera - Camera with Sony IMX477R 12,3MP sensor for Raspberry Pi
ID: 578650
5056561800127
zł229.00
Tax included
zł186.18 tax excl.
Camera for Raspberry Pi minicomputers. Works with all versions of minicomputers with a CSI socket. The camera is equipped with a Sony IMX477R sensor with a resolution of 12.3MPx and a built-in IR filter. Raspberry Pi HQ Camera
Description
The Raspberry Pi HQ camera is the new official camera for Raspberry Pi minicomputers. Works with all versions of minicomputers with a CSI socket. The camera is equipped with a Sony IMX477R sensor with a resolution of 12.3 MPx and a built-in IR filter.
The camera has the option of mounting lenses with CS (6 mm) and C (16 mm) mounts. The kit also includes a C-CS adapter for mounting lenses of both types. The camera has two official lenses: 16 mm telephoto lens and 6 mm wide-angle lens.
Attention!
The kit does not include camera lenses. They must be bought separately.
Installation and configuration of the camera is very intuitive. The exact process of connecting the camera to the Raspberry Pi and starting the device from a minicomputer is shown in the video below. More information on camera configuration and control can be found on the manufacturer's website.
The Raspberry Pi HQ camera is designed for industrial and consumer applications, such as monitoring or automatic systems that require the highest quality video.
Features
- Works with all versions of Raspberry Pi (Raspberry Pi 4 model B, Raspberry Pi 3 model B+, Raspberry Pi 3 model B etc.)
- Sony IMX477R sensor (with backlight)
- Resolution 12.3 MPx
- 7.9 mm sensor diagonal
- 1.55 μm × 1.55 μm pixel size
- Output: RAW12/10/8, COMP8
- Adjustable focus: 12.5 mm to 22.4 mm
- Lens standards: C, CS (C-CS adapter included)
- IR filter
- Cable length: 200 mm
- Tripod mount: 1/4 "- 20
Kit contains
- Raspberry Pi HQ 12.3 MPx camera
- 200 mm FPC cable
- Dust cap
- Adapter for C-CS lenses
- Focusing tool
578650
Data sheet
- Resolution
- 12,3 MPx
- Interface
- MIPI CSI-2
- Sensor
- Sony IMX477R
- IR filter
- Yes
- Lens assembly
- C/CS mount
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
