zł412.96 tax excl.
A set with a 64 MP camera and a 2 DOF control platform designed for Raspberry Pi minicomputers. The camera has an integrated IR filter and autofocus. The control platform is based on two digital servos that allow you to control the position of the camera in two dimensions. ArduCAM B0399B0283
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
A set with a 64 MP camera and a 2 DOF control platform designed for Raspberry Pi minicomputers. The camera is equipped with an integrated IR filter. The control platform is based on two digital servos that allow you to control the position of the camera in two dimensions, making movements of 180 degrees horizontally and 145 degrees vertically. A board with a dedicated controller was used to control the servos. The set will be used as an image sensor in motion tracking applications.
Features
Camera
- Pi Hawk-Eye
- Resolution: 64MP 9152 x 6944
- Frame rate: 1080p30, 720p60, 640x480p60/90
- Integrated IR filter
- Optical Size: 1/1.7"
- Autofocus
- F1.8
- Focal length: 5.1 mm
- Shutter type: rolling shutter
- QBC color filter
- Output format: JPEG, YUV, RGB, RAW10
- Field of view: 84°
- Camera board dimensions: 25 x 24 mm
Servo GH-S37D
- Torque: 0.6 kg/cm at 3.6V, 0.8 kg/cm at 4.8V
- Operating Speed: 0.13sec/60° at 3.6V, 0.09sec/60° at 4.8V
- Operating Voltage: 3.6v~4.8v
- Operating Current: <350mA
- Dead Band: 3 usec
- Dimension: 20 x 8.75 x 22mm
Control Board
- PWM resolution: 12-bit
- Communication interface: I2C
- Operating voltage: 3.3V/5V
- Dimension: 38 x 28 mm
Kit contains
- Pi Hawk-Eye 64 MP camera
- 2 x Digital Servo
- Bracket and bolt kit
- Control board
- 4 x connection cable
Data sheet
- Resolution
- 64 MPx
- Interface
- MIPI CSI-2
- Sensor
- Inna
- IR filter
- Yes
- Lens assembly
- none
