Arducam 12MP Pan Tilt Zoom PTZ Camera - PTZ IMX477 12MP Camera for Raspberry Pi + Base
ID: 585094
5906623403608
zł989.01
Tax included
zł804.07 tax excl.
Camera set with IMX477 sensor with 12 MPx matrix, allows for remote camera rotation, tilt angle and zoom control. Works with Raspberry Pi minicomputers. Swivel base included. ArduCAM B0167B12
Description
The camera set with the IMX477 sensor allows you to remotely rotate the camera, control the angle of inclination and zoom. It works with minicomputers from the Raspberry Pi series, including: Raspberry Pi 4 model B, Raspberry Pi 3 model B+ , Raspberry Pi 3 model B. The sensor used has a matrix with a resolution of 13 MP and allows you to record video in the 7fps @ 4160×3120 format . It has a built-in IR filter. The module is attached to the Raspberry Pi via a dedicated socket. It uses a CSI interface specifically developed for use with cameras. The camera is supported by the latest version of the Raspbian operating system. The camera module comes with a movable PTZ lens, a control board and a base with 2 degrees of freedom (equipped with 2 digital servos DS-3115MG to freely move the camera 180 degrees in both the horizontal and vertical directions). Full documentation is available on the product page.
Features
- Works with Raspberry Pi 4 model B, Raspberry Pi 3 model B+ , Raspberry Pi 3 model B
- Matrix: IMX477
- Matrix resolution: 12 MP
- 1/3 ″ format
- Number of pixels: 4160 × 3120
- Pixel size: 1.1 x 1.1 um
- Viewing angle: 91 ° - 25 ° (horizontal)
- Movable PTZ lens
- Built-in IR filter
- Photo resolution: 4160 × 3120 pixels
- Video:
- 1920×1080 @ 60fps (Jetson Nano/Xavier NX)
- 4032×3040 @ 30fps (Jetson Nano/Xavier NX)
- Full metal, aluminum base
- Base Size: 120 x 120 x 130 mm
Kit contains
- Camera module IMX477 12 MPx
- PTZ lens
- Control board
- Pre-assembled metal base with 2 digital servos
- FFC / FPC 15-pin 30 cm tape
- XH2.54 cable with 30 cm 6-pin female connector
- 4 x distance
585094
Data sheet
- Resolution
- 12,3 MPx
- Interface
- CSI
- Sensor
- Sony IMX477
- IR filter
- Yes
- Lens assembly
- none
