zł466.98 tax excl.
The camera set with the Sony IMX219 sensor allows you to remotely rotate the camera, control the angle of inclination and zoom. Works with all versions of the Raspberry Pi. The camera is equipped with a matrix with a resolution of 8 MPx. ArduCAM B01678MP
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Camera module with Sony IMX219 sensor allows you to remotely rotate the camera, control the angle of inclination and zoom. Works with all versions of Raspberry Pi, including: Raspberry Pi 4 model B, Raspberry Pi 3 model B+ , Raspberry Pi 3 model B. The sensor used has a matrix with a resolution of 8 MP and allows you to record video in the format 1280×720/60fps. It has a built-in IR filter. The module is attached to the Raspberry Pi via a dedicated socket. It uses a CSI interface specifically developed for use with cameras. The board has small dimensions - 36 mm x 36 mm. The camera is supported by the latest version of the Raspbian operating system. The camera module comes with a movable PTZ lens and a control board.
Features
- Works with all versions of the Raspberry Pi
- Matrix: Sony IMX219
- Matrix resolution: 8 MP
- Sensor size: 3.674 x 2.760 mm (1/4″ format)
- Pixel Count: 3280 x 2464 (active pixels) 3296 x 2512 (total pixels)
- Pixel Size: 1.12 x 1.12 um
- The lens can be replaced
- PTZ lens
- Built-in IR filter
- Photo resolution: 3280 x 2464 pixels
- Video:
- 1280 × 720, 60 fps
- 1080p, 30 fps
- 1640 × 1232 with full FOV, up to 30fps
- 3280 × 2464 full FOV, 0.1 to 15 fps
- Dimensions: 36 x 36 mm
Kit contains
- Sony IMX219 8MP camera module
- PTZ lens
- Control board
- FFC/FPC 15-pin 15 cm tape
- XH2.54 Jumper wire with 6Pin Famale Connector
Data sheet
- Resolution
- 8MPx
- Interface
- MIPI CSI-2
- Sensor
- Sony IMX219
- IR filter
- Yes
- Lens assembly
- M12/CS mount
