LCD IPS display 7.9" DSI with touch panel for Raspberry Pi - Waveshare 22293
ID: 1180767
5906623426676
zł370.00
Tax included
zł300.81 tax excl.
IPS 7.9" LCD display with touch panel dedicated for Raspberry Pi. It is equipped with DSI interface for image display and I2C interface for touch screen. Resolution 400x1280 pixels. Waveshare 7.9inch DSI LCD
Description
IPS LCD display with a diagonal of 7.9" with a capacitive touch panel. It was equipped with a DSI interface for displaying the image and I2C for the touch panel. It offers a resolution of 400x1280 pixels and a wide viewing angle. The screen brightness can be adjusted by the user, and the tempered glass panel effectively protects the display against mechanical damage. Works with minicomputer Raspberry Pi. Full documentation with configuration examples is available on the product page.
Attention!
The default display orientation is portrait. It can be programmatically changed to horizontal as described on the product wiki page
Features
- Diagonal: 7.9"
- Resolution: 400 x 1280 px
- Matrix type: LCD IPS
- DSI connector
- Capacitive touch screen (5-point)
- Touch screen interface: I2C
- Wide viewing angle: 170°
- Tempered glass panel
- Works with Raspberry Pi
- Dimensions: 207.78 x 69.8 mm
Kit contains
- 7.9" DSI LCD display
- FPC 15-pin 1.0 mm cable, 50mm long
- A set of screws
1180767
Data sheet
- Screen type
- IPS
- Diagonal (inch)
- 7,9
- Resolution
- 1280 x 480 px
- Interface
- DSI
- Touch
- Yes
