ESP32-S2 TFT Feather - WiFi module with ESP32-S2 chip and LCD TFT display
search
  • ESP32-S2 TFT Feather - WiFi module with ESP32-S2 chip and LCD TFT display
  • ESP32-S2 TFT Feather - WiFi module with ESP32-S2 chip and LCD TFT display
ID: 1178264
zł144.23
Tax included

zł117.26 tax excl.

Module with WiFi Espressif ESP32-S2. It integrates the TFT LCD display, SPI Flash memory, LiPo charging circuit and RGB diode. It is equipped with a STEMMA QT connector. Adafruit 5300

24h
Available
Available quantity: 2


Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

Module with WiFi Espressif ESP32-S2. It has 4 MB of Flash memory, 2 MB of external PSRAM memory, integrated WiFi 802.11 b/g/n transceiver and a JST-PH 2.0 connector for connecting a LiPo battery. The board has a TFT LCD display and an RGB LED. FeatherS2 is easy to integrate with sensors due to the available STEMMA QT connector (Qwiic compatible).

The module offers great possibilities in the field of IoT systems and can be used both to control LEDs and to transfer data to a specific platform. FeatherS2 can also be programmed using the Arduino IDEESP-IDF or CircuitPython. Full documentation is available on the product page.

Features

  • 240MHz 32-bit single-core processor
  • 4 MB SPI Flash Memory
  • 2 MB of additional PSRAM
  • Wi-Fi 2.4 GHz - 802.11b / g / n
  • LCD TFT 1.14 "240x135 px display
  • Optimized power system ensuring low energy consumption
  • LiPo battery management
  • Power, charging and user LEDs
  • USB Type-C
  • LED NeoPixel
  • Qwiic / Stemma Qt connector
  • Compatible with Feather
  • Dimensions: 52.4 x 22.8 x 7.2 mm

Kit contains

  • FeatherS2 module
  • 2 x 16-pin goldpin male connector
1178264
