Espressif ESP32-P4-Function-EV-Board – kit with a 7” LCD display, Wi-Fi, and Bluetooth
ID: 1194760
5906623496587
zł399.00
Tax included
zł324.39 tax excl.
Espressif ESP32-P4-Function-EV-Board – a development board with Wi-Fi 6, Bluetooth 5, a 7” TFT display, a 2 MP camera, and MIPI-CSI/DSI support. Espressif ESP32-P4-Function-EV-Board
Description
The ESP32-P4-Function-EV-Board is a development board based on the ESP32-P4 chip. This system features a dual-core RISC-V processor clocked at 400 MHz and supports up to 32 MB of PSRAM. Additionally, the ESP32-P4 supports USB 2.0, MIPI-CSI/DSI, H.264 encoding, and various peripherals. With its exceptional features, the board is an ideal choice for developing affordable, high-performance, and energy-efficient audio and video products with network connectivity.
The ESP32-C6-MINI-1 module provides Wi-Fi and Bluetooth functionality. The board also includes a 7-inch capacitive touchscreen with a 1024 x 600 resolution and a 2 MP camera with MIPI CSI. This product is well-suited for prototyping a wide range of devices, such as video doorbells, network cameras, smart home control panels, electronic price tags, vehicle dashboards, and more.
Features
- ESP32-P4 processor with dual RISC-V cores and AI instruction set
- Built-in PSRAM: 32 MB
- Flash memory: 4 MB (internal module), 16 MB SPI memory
- Wi-Fi/Bluetooth module: ESP32-C6-MINI-1
- MicroSD card slot
- ES8311 audio codec
- Built-in microphone and speaker output (4 Ω, 3 W)
- Ethernet port: 10/100 Mbps
- USB ports: USB 2.0 Type-C, USB 2.0 Type-A (OTG)
- MIPI-CSI and MIPI-DSI connectors
- Dimensions: 74 x 88 mm
Kit includes
- Main board
- 7” TFT LCD display module
- 2 MP camera module
- Flexible flat cables
- Mounting spacers
