Development board based on the ESP32-C3-MINI-1 module. It offers the ability to connect via WiFi, Bluetooth version 5 and Bluetooth Mesh. It is equipped with sensors, such as the SHTC3 temperature and humidity sensor or the IMU 6 DoF ICM-42670-P sensor. Espressif Systems ESP32-C3-DevKit-RUST-1

24h
Available
Available quantity: 2


Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

ESP32-C3-DevKit-RUST-1 is a development board based on the ESP32-C3-MINI-1 module. It offers the ability to connect via WiFi, Bluetooth version 5 and Bluetooth Mesh, which enables wireless communication of various levels of complexity. It uses a 32-bit, single-core RISC-V processor that runs at up to 160 MHz. This allows you to perform various tasks in real time. It has 384 KB of ROM and 400 KB of SRAM, of which 16 KB is dedicated to the cache.


The board offers a wide set of 22 programmable GPIO pins that can be used for a variety of applications. Among them are interfaces such as 3 x SPI, 2 x UART, 1 x I2C, 1 x I2S. In addition, there are also 2 x 54-bit general purpose timers, 3 x watchdog timers and 1 x 52-bit system clock for precise time management.


The module offers various types of peripherals that are useful in development projects. These include, among others:

  • Remote control peripherals (RMT).
  • LED PWM (LEDC) controller that allows you to control LEDs with precise brightness control.
  • A full-size USB Serial/JTAG controller that allows communication via the USB interface.
  • Generic DMA Controller (GDMA), which allows for efficient management of data transfer operations between different memory areas.
  • TWAI® (Two-Wire Automotive Interface), which is used for communication in automotive systems.
  • 2 x 12-bit SAR ADCs, up to 6 channels, which allows you to read analog signals.

In addition, the board is equipped with sensors, such as the SHTC3 temperature and humidity sensor or the IMU 6 DoF ICM-42670-P sensor, which allows you to measure movement and orientation. There is also an addressable RGB LED, which opens up possibilities for creating lighting effects.

The board can be powered by a Li-Ion battery, and communication and power take place via a USB type C connector. ESP32-C3-DevKit-RUST-1 is a comprehensive development board that allows you to explore and develop a variety of projects using advanced communication, sensory and sensor functions and interfaces. It will be used in e.g. in the area of IoT.

The set can be programmed in Rust. The manufacturer has prepared a guide to help you start programming in Rust, available at.

Features

  • ESP32-C3-MINI-1 module
  • Complies with the IEEE 802.11 b/g/n standard
  • Bluetooth 5, Bluetooth Mesh
  • 32-bit single-core RISC-V processor, up to 160 MHz
  • 384KB of ROM
  • 400 KB SRAM (16 KB for cache)
  • 8KB SRAM in RTC format
  • 22 x programmable GPIOs:
    • 3 x SPI
    • 2 x UARTs
    • 1 x I2C
    • 1 x I2S
    • 2 x 54-bit general purpose timers
    • 3 x watchdog timers
    • 1 x 52-bit system clock
  • Remote Control Peripheral (RMT)
  • PWM LED Controller (LEDC)
  • Full-size USB Serial/JTAG controller
  • Generic DMA Controller (GDMA)
  • TWAI®
  • 2 x 12-bit SAR ADCs, up to 6 channels
  • SHTC3 temperature and humidity sensor
  • IMU 6 DoF Sensor ICM-42670-P
  • Addressable RGB LED
  • Li-ion charger
  • USB Type-C connector
  • Reset button
