LCD-CC-1602C-FHW-K/W-E6 fl C – BIG 16×2 alphanumeric display, black characters, white background
ID: 1199515
5902186308275
zł36.85
Tax included
zł29.96 tax excl.
LCD-CC-1602C-FHW-K/W-E6 fl C offers large, clear characters and high contrast thanks to FSTN negative technology. Compatibility with the HD44780 controller and parallel interface facilitates use in measuring devices, control systems, and operator panels.
Description
16×2 alphanumeric LCD display with large 9.66 mm characters, made with FSTN negative technology, providing clear black characters on a white background. Built-in LED backlighting improves readability in various lighting conditions. The HD44780 or compatible controller enables operation in 4-bit or 8-bit parallel interface mode, facilitating integration with microcontrollers and Arduino modules. The display operates in an extended temperature range and has a 6 o’clock viewing angle, ensuring optimal visibility when mounted in panels and measuring devices.
Properties
- type: alphanumeric LCD display
- configuration: 2 lines × 16 characters
- character height: 9.66 mm (BIG)
- controller: HD44780 or compatible
- interface: parallel 4-bit or 8-bit
- technology: FSTN negative
- character color: black
- background color: white
- backlight: white LED
- viewing angle: 6 o’clock
- PCB dimensions: 122 × 44 mm
- active area dimensions: 94.80 × 20 mm
- operating temperature: from −20 °C to +70 °C
1199515
Data sheet
- Screen type
- LCD alfanumeric
- Diagonal (inch)
- Nie dotyczy
- Resolution
- 2 x 16 characters
- Interface
- Parallel
- Touch
- No
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
