BH1745 Luminance and Color Sensor Breakout - module with color and light intensity sensor
ID: 585246
606034878044
zł55.24
Tax included
zł44.91 tax excl.
Module with color and light intensity sensor. Offers a wide detection range and two LED backlights. It communicates via the I2C bus. It communicates via the I2C bus. Pimoroni PIM375
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Module with color and light intensity sensor. It offers a wide sensing range, 50/60 Hz light noise suppression and two LED backlights. It communicates via the I2C bus and is powered with a voltage from 3 to 6 V. These types of sensors are widely used in phones, tablets and laptops, where they are used to detect the ambient light temperature and adjust the brightness of the display accordingly. Documentation with a library and examples in Python is available in the GitHub repository.
Features
- Light intensity and color sensor BH1745
- Two white LEDs
- Red, green, blue and luminance color measurements
- Detection range from 0.005 to 40,000 lux
- Light noise suppression 50/60 Hz
- IR cut-off filter
- 16 bit data output
- Reverse polarity protection
- Compatible with Raspberry Pi 3B+, 3, 2, B+, A+, Zero, Zero W and Arduino
- I2C interface
- I2C address: 0x38 or 0x39
- Supply voltage: 2 to 6 V
- Dimensions: 19 x 19 x 3 mm
Kit contains
- BH1745 Luminance and Colour Sensor Breakout
- 1x5 male header
- 1x5 female right angle header
