Compact development kit from the M5Stick series equipped with ESP32 Pico and display and MLX90640 matrix. It will work well in projects related to IoT or as a STEM educational tool, e.g. as a small thermal imaging camera. M5 Stack K126

24h
Available
Available quantity: 1

Description

M5Stick T-Lite is a compact development kit from the M5Stick series equipped with ESP32 Pico and MLX90640 sensor, i.e. thermal imaging matrix. ESP32 Pico is a module with a dual-core 32-bit Xtensa 240 MHz LX6 processor. It offers Wi-Fi and Bluetooth communication and has a built-in 4 MB Flash memory.

The M5Stick set has a USB type C interface, which is used for charging, programming and serial communication, and an integrated 1.14" screen. It is powered by a 160 mAh battery managed by the AXP192 chip. The M5Stick also has a built-in buzzer and microphone.

The MLX90640 is the MLX90640 infrared sensor, which is actually a 32x24 pixel measurement matrix. It enables temperature measurement in the range from -40 to 300°C with an accuracy of 1°C. The camera has a viewing angle of 110°x75°, and communication with the sensor takes place via the I2C interface. As feedback, it sends data independently for each pixel (obtaining the temperature, however, requires complex calculations) with a refresh rate of up to 64 Hz. The sensor can be used as a low-resolution thermal imaging camera.


M5Stick T-Lite can be programmed by Arduino and UIFlow (using Blockly, a MicroPython language). The set is perfect for IoT-related projects, as a STEM educational tool or in wearable devices. Full documentation of the kit is available on the manufacturer's website.

Features

  • ESP32-PICO: 240MHz, Dual Core, 600DMIPS, 520KB SRAM, Wi-Fi, Bluetooth
  • Flash 4 MB
  • Interface: USB type C, GROVE (I2C + I/O + UART)
  • LCD TFT display 1.14", 135x240 px, ST7789v2
  • GPIO pins
  • SPM1423 microphone
  • PMU AXP192
  • MLX90640 sensor:
    • Matrix 32x24
    • Range of measured temperatures: from -40°C to 300°C
    • Accuracy: ± 1°C
    • Viewing angle: 110°x75°
    • Refresh rate: 0.5 to 64 Hz
  • 160mAh 3.7V battery
  • Antenna 2.4G 3D Antenna
  • Case: PC
  • Power supply: 5V/500mA
  • Dimensions: 69 x 26.6 x 6.35mm
  • Weight: 30g
1186525

Data sheet

Microcontroller
ESP32
Flash memory
4 MB
Number of I/O
08
Ethernet
none
WiFi/BT module
No
Bluetooth module
No
MicroSD slot
No
Length
69 mm
Width
27 mm
USB connector type
USB type C
