zł403.25 tax excl.
The clamp meter allows you to measure AC voltage up to 600 V, AC current up to 3000 A, resistance and frequency. Equipped with a flexible measuring coil. Uni-T UT281E
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
The clamp meter allows you to measure AC voltage up to 600 V, AC current up to 3000 A, resistance and frequency. It is equipped with a flexible Rogowski measuring coil.
1. Rogowski Coil | 5. INRUSH |
2. Clamp Lock | 6. Range |
3. LCD | 7. Power |
4. HOLD | 8. Voltage and resistance input |
The device meets the requirements of IP54 and resistance to falls from a height of 2 m. Due to its ease of use, accurate readings, stable operation and reliable quality, it is an ideal tool for electricians.
Features
- Parameters measurement
- AC Voltage (V): 6V / 60V / 600V ± (1.2% + 3)
- AC Current (A): 30A / 300A / 3000A ± (3% + 5)
- Inrush current 0.5A to 3000A (for reference)
- Frequency response 45Hz to 500Hz (sine wave)
- Resistance (Ω): 6kΩ / 60kΩ / 600kΩ / 6MΩ ± (1.2% + 3)
- Frequency (Hz): 20Hz to 30kHz ± (1% + 2)
- Functions
- Auto range selection (manual range available in current measurement)
- Flex coil size 45.7 cm, radius: 8 cm
- Display counter up to 6000
- Refresh rate 3 times / sec
- True RMS
- Dual Display Interface (LCD)
- Hold / Buzzer
- Automatic shutdown
- Low battery indicator
- Backlight / function selection
- 2m drop test
- General
- Power supply: 3 x 1.5 V battery (R03)
- LCD size: 32 x 34 mm
- Color: Red-gray
- Dimensions: 325 x 180 x 30 mm
- Weight 250 g
Kit contains
- The clamp meter UT281E
- Test leads
- Battery
- Transport bag
- Instruction
Data sheet
- Zakres pomiarowy napięcia DC
- Brak
- Zakres pomiarowy napięcia AC
- 4 V/40 V/400 V/600 V
- Zakres pomiarowy natężenia DC
- Brak
- Zakres pomiarowy natężenia AC
- 3000 A
- Zakres pomiarowy rezystancji
- 60 MΩ
- Zakres pomiarowy pojemności
- Brak
- Zakres pomiarowy częstotliwości
- 20 Hz - 30 kHz
- Pomiar temperatury
- Nie
- Regulacja zakresu pomiarowego
- Automatyczna
- True RMS
- Tak
- Funkcja Hold
- Tak
- Tester ciągłości obwodu
- Brak
- Tester diod
- Nie
- Pomiar hFE tranzystorów
- Nie
- Buzzer
- Tak
- Wskaźnik rozładowanej baterii
- Tak
- Automatyczny wyłącznik
- Tak
- Podświetlenie wyświetlacza
- Tak
- Battery type
- AAA
- Length
- 325 mm
- Width
- 180 mm
- Thickness
- 30 mm
- Weight
- 250 g
