8 Channel USB Relay Module - module with 8 12V relays and a USB interface
ID: 1180979
zł441.59
Tax included
zł359.02 tax excl.
Module with 8 relays 12 V with a maximum switching current of 7 A. Communicates via the USB interface. Numato Lab RL80001
Description
Module with 8 relays supporting communication via USB. It can control devices with a voltage of 12 V and a current of up to 7 A. The USB interface makes it easy for the user to connect the module to any devices with Windows, Linux, Mac or embedded computers such as RPi. It comes with built-in software that supports simple commands to control the relays and read their status. The board appears as a serial port when connected to a computer and can be operated by serial terminal applications such as HyperTerminal or Putty. Perfect for automation systems that require the control of multiple devices. Full documentation is available on the product page.
Features
- 8 relays SPDT 12V
- Switching current 7 A
- USB interface with CDC support
- Relay contacts available on screw terminals
- Digital circuits can be powered from USB or an external power source
- It can be controlled by standard serial console applications
- Dimensions: 100.228 x 79.997 x 20 mm
1180979
Data sheet
- Output current
- 7 A
- Number of channels
- 8
- Executive element
- Przekaźnik
- Coil voltage
- 12 VDC
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
