DC motor driver that allows you to control the movement of two drives using the I2C interface. Board with soldered connectors. Pololu 5036

6 weeks
On request
Kamami is the official distributor of electronic modules and Pololu robotic parts. All products of this brand in our offer are original and come directly from the manufacturer.



Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

DC motor driver dedicated to Arduino boards. It allows you to control the movement of two drives using the I2C interface. It can work with motors with a supply voltage from 6.5 to 30 V and has a capacity of up to 18 A per motor (continuous operation). The controller has a built-in protection in the event of loss of communication with Arduino and the ability to configure the response if an error occurs. The user can set the maximum acceleration and the starting speed of the motor, and the shield construction allows you to connect the drivers with each other. The manufacturer's website includes a user manual and a library with sample programs.

Features

  • Wide operating voltage range: 6.5 V to 30 V
  • Maximum output current per motor: 18 A
  • Reverse-voltage protection on motor power supply
  • Logic voltage range: 3 V to 5.5 V
  • Control interface: I²C
  • I²C clock speed: up to 400 kHz
  • Optional cyclic redundancy checking (CRC)
  • Configurable motion parameters:
    • Max acceleration/deceleration forward/reverse
    • Starting speed forward/reverse
    • Direction change delay forward/reverse
  • PWM frequency: eight options available from 1 kHz to 80 kHz
  • Command timeout feature stops motors if the Arduino stops functioning
  • Configurable automatic error response
  • Motor power supply (VIN) voltage measurement
  • Optional pins make it easy to power the Arduino from reverse-protected motor power, either directly or through an external regulator (not included)
  • Two status LEDs
  • Motor direction indicator LEDs
1181151

Data sheet

Output current
18 A
Number of channels
2
Supply voltage min
6,5 V
Supply voltages max
30 V
