Reduced price! UT352 volume level meter View larger

UT352 volume level meter

Volume level meter UT352, UNI-T

More details

ID: 233245

70,11€

-2,75€

67,36€ gross (23% VAT)
54,76€ net

Add to wishlist

More info

Volume level meter UT352, UNI-T

Range: 30 - 130 dB
Accuracy: +/- 1.5dB
Ranges: 30 - 80 dB, 50 - 100 dB, 60 - 110 dB, 80 - 130 dB
Frequency range: 31.5 - 8000 Hz
Frequency ratio selection: A / C
Time selection:
- FAST (fast): every 125ms
- SLOW (slow): every 1s
Barrier: 30 - 130 dB
outputs:
- AC: 0.707 V RMS (whole scale), output impedance: approx. 600 ohms
- DC: 2 V RMS (whole scale), 10mV / dB, output impedance: approx.100 Ohm
Special functions:
- Warnings: above "OVER" / below "UNDER" range
- minimum / maximum value
- stopping the last indication
- display backlight
- sleep operation
- low battery indicator (4.8V)
- memory of 63 readings
Power: 4x 1.5V battery (AA)
LCD size: 53 x 41 mm
Overall dimensions: 273 x 70 x 39 mm
Weight: 390g

Manufacturer
