Hantek 6022BE - 2-channel 20MHz digital oscilloscope
ID: 1183455
5906623435074
zł317.68
zł285.00
Save zł32.68
Tax included
zł231.71 tax excl.
Lowest price 30 days:
zł317.68
A 2-channel digital oscilloscope that connects to a computer via a USB interface. It offers a frequency bandwidth of 20 MHz and sampling up to 48 MS/s. Hantek 6022BE
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
A 2-channel digital oscilloscope that connects to a computer via USB interface. Ccharacterized by a bandwidth of 20 MHz and a sampling rate of 48 MSa/s. It has no built-in display, and requires a computer with dedicated software to work properly. It has 23 built-in measurement functions and PASS/FAIL control. The device requires no additional power supply - both communication and power are provided via a USB interface. Two measurement probes are included, as well as a set of cables and measurement clips for the analyzer. The oscilloscope can work with Windows 7, 8, 10 operating systems and LabVIEW software.
Features
- Number of channels: 2
- Bandwidth: 20 MHz
- Sampling rate: 48 MS/s
- Memory depth: 1 M
- Time base range: 4ns to 5 ks
- Input impedance: 1MΩ 25pF
- Input sensitivity: 20 mV to 5 V
- Vertical resolution: 8 bits
- DC accuracy: ± 3%
- Trigger source CH1, CH2
- Input protection: diodes
- X-Y graph
- Trigger mode: Auto, Normal and Single
- Trigger slope: +/-
- Adjustable trigger level
- Trigger type: rising edge, falling edge
- Measurement functions: FFT, addition, subtraction, multiplication, division
- USB 2.0 communication
- USBXI connector
- Compatible with LabVIEW
- Supported systems: Windows 7, 8, 10
- Power supply: USB
- Dimensions: 200 x 100 x 35 mm
- Weight: 300 g
Kit contains
- Hantek 6022BE
- 2 x measuring probe
- User manual
- USB cable
- PC software
1183455
Data sheet
- Type of oscilloscope
- Digital
- Bandwidth
- 20 MHz
- Sampling rate
- 48 MS/s
- Memory depth
- 1 Mpts
- Number of channels
- 2
