ZL14PLD - dipPLD module with XC2C256 (CoolRunner-II from Xilinx)

Description

DipPLD module is a module with XC2C256 (CoolRunner-II from Xilinx). DipPLD module was designed to make easier common using of CPLD chips by constructors, which can not or will not invest in automated component mounting system of elements with small pitch (0.5mm).

Features

• CPLD XC2C256 chip (256 macrocells) from CoolRunner-II family in VQFP100 package
• 16 lines with buffers adjusted to 5V signals
• Embedded clock frequency adjusted generator and oscillator 32.768kHz
• Module adapted to using with ZL15PLD board
• JTAG 10-pin connector (cooperate with e.g. the JTAG ZL11PRG interface)
• Signals on pin connectors
• Module power supply: 5VDC

Kit content

• assembled DIP module with XC2C256-7VQG100C chip
