VM140 - A prototype card of a usb interface

Description

Port in / out card with optoisolation.
The I / O card contains 33 digital and analog input and output ports. The connection to the computer is opto-insulated, which protects the PC against damage.
All communication procedures have been developed in the form of Dynamic Link Library (DLL) libraries. The system works under Windows (98SE, 2000, Me, XP) and allows you to use Delphi, Visual Basic, C ++ Builder and other applications.

properties

• 8 analogue inputs 10 bit: 0.5 or 10VDC / 20kohm
• 8 analogue outputs 8 bit: 0.5V or 10VDC / 47ohm
• 8 digital open collector type inputs with LED indicator on the board
• 8 digital open collector outputs (max 50V / 100mA) with LED indicator on the board
• One PWM output 10 bit: 0 to 100% open collector output (max 100mA / 40V) with LED indicator on the PCB
• Response time: 4ms / command
• Compatible with USB 2.0 and 1.1 (USB cable included)
• Power consumption via USB port: about 60mA
• Number of cards connected to a PC max 8
• Power supply: 12Vdc / 300 mA power supply
• PWM frequency: 15.6 KHz
• The dimensions of the PCB 195 x 142 x 20mm
• Minimum hardware requirements:
• Pentium class CPU
• USB1.1 port
• Windows 98SE, 2000, Me, XP (except Win NT) - Windows XP games
• CD ROM and mouse
