- Out-of-Stock
Siemens LOGO starter kit! 8 PROMO
ID: 563424
5906623477852
Logic module (controller) LOGO! 12 / 24RCE with Ethernet (S7, Modbus TCP) and display, 12 / 24V DC, data logging on micro SD cards, built-in WEB SERVER, expandable with additional modules. Siemens LOGO! 12/24 RCE 6ED1052-1MD08-0BA1
Description
LOGO! 8 is the next generation of logic modules. The new model will meet all expectations of the user thanks to simplified operation, a new display and a maximally simplified configuration of Ethernet communication. An additional advantage of LOGO! 8 there is a built-in Web server. Dedicated GSM / GPS module allows remote communication over the cellular network, which increases the scope of LOGO! 8 digital inputs, 4 relay outputs, 400 memory blocks, operates at a temperature of -22 to 55 degrees C. Due to the use of a real-time clock, applications requiring the temporary switching of devices, such as streetlights, fan rooms, pumping stations and others can be used.
Attention!
The 6ED1052-1MD08-0BA1 requires the Logo! Soft Comfort v8.3 or higher software to work properly. Upgrade to this version is available after registering an account and passing verification on the manufacturer's website: https://support.industry.siemens.com/cs/document/109783154/download-for-logo!-8-3-software-upgrade?dti=0&lc=en-WWLOGO! allows you to control lighting, blinds, shutters, heating and air conditioning systems and a number of other devices. It is also used in industry: for the construction of machine control and automation systems. It has approvals for applications on marine vessels. Thanks to the use of intelligent LOGO! installation and commissioning time is optimized. Expenditures related to making electrical connections with respect to conventional controls based on relays and contactors are minimized. An important advantage of LOGO! is the ease of programming. We create the program by combining ready-made function blocks.
properties
- Logic module with ethernet and display
- Data logging on MICRO SD cards
- Built-in WEB SERVER
- 12/24 V DC power supply
- 8 binary inputs (including 4 analog voltage inputs)
- 4 relay outputs (3 A)
- 400 blocks memory
- It can be expanded with additional modules
- The ability to work in the temperature range from -22 to +55 degrees Celsius
- Dimensions: 71.5 x 90 x 60 mm
Included
- Logic LOGO! 12 / 24RC
- LOGO! Software Soft Comfort 8.1
NOTE: promotional sets are sold individually!
563424
Manufacturer SIEMENS SPÓŁKA Z OGRANICZONĄ ODPOWIEDZIALNOŚCIĄ Żupnicza 11 03-821 Warszawa Poland reklamacje.ebok.pl@siemens.com
Responsible person SIEMENS SPÓŁKA Z OGRANICZONĄ ODPOWIEDZIALNOŚCIĄ Żupnicza 11 03-821 Warszawa Poland reklamacje.ebok.pl@siemens.com
