SIM7600G-H 4G LTE Cat-4 GNSS module with SMA antenna (B) - Waveshare 24011
ID: 1184107
5906623427376
zł267.14
Tax included
zł217.19 tax excl.
SIM7600G-H 4G CommunicaLTE Cat 4 module that supports wireless communication over LTE-TDD, LTE-FDD, HSPA+, GSM, GPRS and EDGE technologies. SMA antenna included. Waveshare SIM7600G-H 4G Module (B)tion Module, Multi-band Support, Compatible with 4G/3G/2G, With GNSS Positioning. SIM7600G-H 4G Module (B)
Description
The SIM7600G-H is an LTE Cat 4 module that supports wireless communications over LTE-TDD, LTE-FDD, HSPA+, GSM, GPRS and EDGE technologies. It offers maximum download speeds of up to 150 Mbps and upload speeds of up to 50 Mbps. The module is equipped with a UART interface available on 2.54 mm raster connectors, so it can be easily connected to popular development kits. The built-in USB port, on the other hand, allows it to be connected to, for example, Raspberry Pi or NVIDIA Jetson Nano minicomputers. The module allows the use of all basic GNSS positioning satellite systems with many built-in network protocols. It supports driver support for major operating systems (USB driver for Windows, Linux and Android, etc.) and configuration via AT commands. Software updates can be performed via USB interface. Full documentation with examples of use are available on the product page.
Features
- Frequency band
- LTE-FDD: B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B25, B26, B28, B66
- LTE-TDD: B34, B38, B39, B40, B41
- WCDMA: B1, B2, B4, B5, B6, B8, B19
- GSM: 850, 900, 1800, 1900 MHz
- GNSS: GPS, Beidou, GLONASS, GALILEO, QZSS
- Data transfer:
- LTE 150 Mbps (download), 50 Mbps (upload)
- HSPA+ 42 Mbps (download), 5.76 Mbps (upload)
- WCDMA 384 kbps (download), 384 kbps (upload)
- EDGE 236.8 Kbps (DL), 236.8 Kbps (UL)
- GPRS 85.6 Kbps (download), 85.6 Kbps (upload)
- Windows/Linux/Android operating system
- Protocol TCP, IP, IPV4, IPV6, Multi-PDP, FTP, FTPS, HTTP, HTTPS, DNS
- SMS supports MT, MO, CB, text, PDU
- USB software update
- SIM card 1.8V/3.0V
- SMA antenna (LTE main antenna), IPEX-1 antenna interface connector (LTE collective antenna + GNSS antenna)
- Power supply 3V to 3.6V
- UART interface
- Operating temperature from -30℃ to +80℃
- Dimensions: 38.8 x 42 mm
Kit contains
- SIM7600G-H 4G module
- 4G antenna
