TMC5072-BOB – breakout board with stepper motor controller based on the TMC5130A-TA chip
search
  • TMC5072-BOB – breakout board with stepper motor controller based on the TMC5130A-TA chip
ID: 572588
zł116.73
Tax included

zł94.90 tax excl.

TMC5130A-BOB is a compact breakout board with the TMC5130A-TA chip, designed for rapid prototyping of motion control solutions. Its high microstepping resolution, encoder support, and wide operating voltage range make it a suitable choice for projects such as 3D printers, CNC axis controllers, and robotic manipulators.

24h
Available
Available quantity: 8

Description

The TMC5130A-BOB board is a development module featuring the TMC5130A-TA chip, enabling control of a single two-phase stepper motor in positioning or velocity mode. The integrated motion controller and driver provide precise microstepping up to 256 microsteps per step and support for ABN encoders. Communication with the board is possible via SPI or Step/Dir interfaces. The chip supports advanced operation modes such as SixPoint Ramp, SpreadCycle, and StealthChop for quiet operation. It supports a supply voltage range of 4.75 V to 46 V and a maximum output current of 1.2 A RMS. This board facilitates rapid prototyping in industrial automation, CNC systems, robotics, and other applications requiring precise motor control.

Features

  • Control of a single two-phase stepper motor
  • Supply voltage range: 4.75 V – 46 V DC
  • Maximum output current: 1.2 A RMS
  • Microstepping: up to 1/256 step
  • Operating modes: positioning, velocity, SixPoint Ramp
  • ABN encoder support
  • Communication interfaces: SPI, Step/Dir
  • Logic power supply: 3.3 V / 5 V
  • Built-in features: StealthChop, SpreadCycle
  • Protections: overcurrent, short-circuit, undervoltage
572588

Data sheet

Output current
1,2 A
Number of channels
1
Supply voltage min
4,75 V
Supply voltages max
46 V
