5.5'' OLED-Display with Capacitive Touchscreen
search
  • 5.5'' OLED-Display with Capacitive Touchscreen
  • 5.5'' OLED-Display with Capacitive Touchscreen
ID: 572469
zł687.47
Tax included

zł558.92 tax excl.

AMOLED 5.5" display with 1920x1080 resolution and 60Hz refresh rate. The display is equipped with a capacitive touch screen with support for up to 10 points as part of the Multi-touch function. Compatible with Lattepanda, Raspberry Pi and other devices with HDMI output. DFRobot DFR0524

4 weeks
On request
Kamami is the official distributor of DFRobot modules and development kits. All boards of this brand in our offer are original and come directly from the manufacturer.



Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

AMOLED 5.5" display with a resolution of 1920 x 1080 and a refresh rate of 60 Hz. The display is equipped with a capacitive touch screen with support for up to 10 points as part of the Multi-touch function. The device has an HDMI output with an adapter compatible with Raspberry Pi minicomputers and a connector Micro-USB for touch interface. The display does not require driver installation. It does not require an additional power supply, as it can be directly powered via the USB port.

The display can be used with Lattepanda, Raspberry Pi and other devices with HDMI output. It has special mounting holes for connecting the Raspberry Pi minicomputer directly at the back of the display.

A detailed description and specification of the product along with an example configuration is available on the website.

Attention!

The screen supports two operating system: Windows and Linux (touchscreen is not available for MacOS).
The video cables shown in the picture are not included in the set.

Features

  • Diagonal: 5.5 inches
  • Screen resolution: 1920 x 1080 pixels
  • Screen type: AMOLED
  • Capacitive touch screen
  • Adjusting the software backlight
  • Refresh rate: 60 Hz
  • Viewing angle: 160 °
  • Video interface: HDMI
  • Touch interface: microUSB
  • Multi-touch points support: 10
  • Supply voltage: 5 V
  • Power consumption: 700 mA
  • Display area: 68.3 x 121.42 mm
  • Contour dimension: 124 x 71 mm
  • Mounting hole size: M2.5
  • External position of the mounting hole: 95 x 64 mm
  • Internal mounting hole position: 58 x 49 mm

Kit contains

  • 5.5'' HDMI OLED-Display with Capacitive Touchscreen
  • Raspberry Pi HDMI Adapter
  • 8 x M2.5*8+6  Standoffs
  • 8 x M2.5*6 DK4.9 Machine Screws
572469

Data sheet

Screen type
AMOLED
Diagonal (inch)
5,5
Resolution
1920 x 1080 px
Interface
HDMI
Touch
Yes
