Module with active low-pass filter 22-300Hz
ID: 587874
5906623464845
zł13.68
Tax included
zł11.12 tax excl.
Module with active low-pass filter. Dedicated to the bass column (subwoofer)
Description
Module with active low-pass filter. The input and output signals are connected via screw connections. Two potentiometers allow you to smoothly adjust the gain and cut-off frequency in the range from 22 Hz to 300 Hz. Thanks to the filter used, only the low tones (bass) are amplified, which is why the module is dedicated to bass speakers (subwoofer). The board should be connected between the audio input and the power amplifier. It works well in home and car audio systems.
Features
- Active low-pass filter
- Potentiometer for gain adjustment
- Potentiometer for adjusting the cut-off frequency: 22 Hz to 300 Hz
- Input: ARK screw connection
- Output: ARK screw connection
- Power supply: voltage 10 to 24 V DC
- Dimensions: 78 x 32 mm
587874
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
