Evaluation Board for dipAVR Mini-module

24h
Available
Available quantity: 12

Evaluation Board for dipAVR Mini-module

ZL8AVR is a versatile evaluation board designed for engineers and hobbyists who want to prototype systems based on AVR ATmega microcontrollers. ZL8AVR is prepared to operate with dipAVR mini-modules (ZL7AVR, ZL12AVR). Board's configuration is complete and user can find on the board the following components: USB interface connector (for ZL1USB module), RS232 interface with DB9F connector, simple keyboard (4 buttons), 8 LEDs, JTAG connector and socket for LCD display (2x16 characters).

Basic features:

  • socket for dipAVR mini-module:
    - ZL7AVR with ATmega128,
    - ZL12AVR with ATmega16,
  • RS232 interface (with level converter and DB9F connector)
  • 10 pin JTAG connector
  • Built-in 5V voltage regulator
  • Socket for LCD 2x16 character display (LCD1602 module)
  • 8 LEDs
  • MMC Flash card connector
  • 4 microswitches
  • Socket for UARTUSB converter (ZL1USB, ZL4USB)
  • Prototype design area
  • USB (5V) or external (9...12VDC) power supply
  • Dimensions: 100 x 165 x 20 mm

Standard equipment:

  • Assembled ZL8AVR board (without dipAVR mini-module and LCD display)

Manufacturer: Kamami
