KAmodTEM
ID: 102922
5906623432288
zł19.90
Tax included
zł16.18 tax excl.
Module with digital thermal sensor, thermostat and I2C interface
Module with digital thermal sensor, thermostat and I2C interface
KAmodTEM makes it easy to use thermal sensor with any device equipped with I2C interface, it can also be used as thermostat.
Basic features:
- MCP9801 thermal sensor by Microchip
- Programmable sensor resolution: 9 to 12 bits
- Sampling frequency 4...33Hz
- Capable of reading temperatures from -55 to +125°C
- SMbus and I2C/400kHz interfaces
- 3 configurable address lines (up to 8 modules on one I2C bus)
- Address 1001xxx (xxx – A2/A1/A0 configurable by jumpers, default 000)
- Alert output (thermostat, open-drain)
- Supply voltage 2.7...5.5VDC
- Built-in pull-up resistors for I2C
- Built-in LED (for example can be used as alert indicator)
- I2C Kamami standard connector (compatible with most of Kamami evaluation boards)
- Dimensions: 30 x 50 x 15 mm
Standard equipment:
- Assembled module
102922
Data sheet
- Interface
- I2C
- Type of sensor
- MCP9801
- Power supply voltage
- 2.7..5.5V
- Sensor type
- Temperatury
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
