Raspberry Pi v3 SA31VA30P camera sensor
ID: 1198421
5056561805900
zł89.90
Tax included
zł73.09 tax excl.
SA31VA30P is a standard camera sensor with an IR filter, offering high image quality and faithful color reproduction – suitable for universal applications in monitoring systems, robotics and educational projects
Description
The SA31VA30P sensor, equipped with a 4.74mm lens and an IR filter, ensures accurate color reproduction while maintaining a classic 75° diagonal field of view. The Sony IMX708 sensor with autofocus and HDR support offers high image quality and great detail. Designed for applications in machine vision systems requiring natural color reproduction. Compatible with the libcamera and Picamera2 libraries.
Features
- Sensor: Sony IMX708
- Resolution: 11.9MP
- Lens: 4.74mm, F1.8
- IR filter: yes
- Autofocus: phase detection
- Angle of view: 75° / 66° / 41°
- Focus range: 10cm to ∞
- Operating temperature: 0–50°C
- Compatibility: libcamera, Picamera2
1198421
Data sheet
- Resolution
- 11,9 Mpx
- Interface
- SLVS-EC 8Lane
- Sensor
- IMX708
- IR filter
- Yes
- Lens assembly
- none
