Baseboard CM4-IO-BASE-B for Raspberry Pi CM4 - Waveshare 19602
ID: 585020
5906623425495
zł113.82
Tax included
zł92.54 tax excl.
Base board prepared for Raspberry Pi CM4 modules. It is equipped with connectors for all available interfaces, additionally on the board there is a RTC system and a fan connector. Waveshare CM4-IO-BASE-B
Description
Base board designed for Raspberry Pi CM4 modules. It is equipped with special connectors for connecting the module and the outputs of all CM4 module interfaces, including USB, Ethernet, HDMI, DSI, two CSI connectors, 40-Pin GPIO connector compatible with HAT modules. The Mini Base Board is additionally equipped with a real-time clock (RTC) chip, a backup battery socket as well as a fan connector and a microSD card slot. At the bottom of the board there is also an M.2 connector for connecting additional modules or a disk and an FFC connector with a USB 2.0 and HDMI interface. Full documentation is available on the product Wiki page.
The 40-pin connector is color-coded, which makes it easy to connect expansion modules. The board has compact dimensions (85 x 56 mm) corresponding to the dimensions of the Raspberry Pi 4 model B minicomputers, thanks to which, after connecting the Raspberry Pi CM4 module (not included), it can be a replacement for standard Raspberry Pi minicomputers.
Features
- CM4 connector: suitable for all variants of the Raspberry Pi CM4 module (not included)
- Standard 40-pin Raspberry Pi HAT connector
- Real time clock (RTC) with battery backup
- HDMI connector
- 2 x CSI camera connector
- DSI Display Connectors
- RJ45 Gigabit Ethernet connector
- Built-in USB Hub with 2 USB 2.0 connectors
- USB type C connector for power and programming
- MicroSD card slot
- 5V PWM fan controller with feedback
- Type C USB power supply
- Dimensions: 85 x 56 mm
Kit contains
- CM4-IO-BASE-B module
- Mounting screw
585020
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
