Compact current sensor Pololu 5308 based on the CT432-HSWF70DR, designed for measuring currents from 0 to 70A at 5V supply in applications requiring galvanic isolation and analog voltage output. Pololu 5308

24h
Available
Available quantity: 3
Kamami is the official distributor of electronic modules and Pololu robotic parts. All products of this brand in our offer are original and come directly from the manufacturer.

Description

Compact current sensor based on the CT432-HSWF70DR, designed for measuring DC current in the range of 0–70 A at a nominal supply voltage of 5 V. Measurement is performed using TMR (tunneling magnetoresistance) technology in an isolated current path with very low resistance (approx. 1 mΩ), which reduces power losses and minimizes the impact of the sensor on the measured circuit.


The output signal is an analog voltage proportional to the measured current, with a zero-current output level of approximately 0.5 V. The module features a wide bandwidth up to 1 MHz and a fast response time of approximately 300 ns, enabling monitoring of rapidly changing currents in power electronics and switching applications. The sensor includes an FLT output that indicates when the current exceeds the allowable measurement range, supporting protection and diagnostic systems.

Features

  • sensing IC: CT432-HSWF70DR
  • sensing technology: TMR (tunneling magnetoresistance)
  • current measurement range: 0 – 70 A
  • current type: DC (unidirectional)
  • supply voltage: 4.75 – 5.5 V
  • nominal voltage: 5 V
  • output type: analog voltage proportional to current
  • sensitivity: 57.1 mV/A
  • zero-current output voltage: approx. 0.5 V
  • bandwidth: up to 1 MHz
  • response time: approx. 300 ns
  • primary current path resistance: approx. 1 mΩ
  • measurement method: series, galvanically isolated
  • FLT output (overcurrent indication)
  • FLT threshold: approx. 110% of measurement range
  • supply current: approx. 6 mA
  • PCB: 4-layer, 2 oz copper
  • signal pin pitch: 2.54 mm
  • dimensions: 0.8″ × 1.1″ (approx. 20.3 × 27.9 mm)
  • weight: approx. 2.3 g
  • operating temperature: -40°C to +125°C
  • manufacturer: Pololu
  • manufacturer code: 5308
1194437

Data sheet

Interface
Sygnał analogowy
Zakres pomiarowy
0 - 70 A
Sposób podłączenia
Szeregowy
