- New
Rigol DHO804 - 4-channel 70MHz digital oscilloscope
ID: 1194342
5902186309364
zł1,874.67
Tax included
zł1,524.12 tax excl.
A compact and cost-effective digital oscilloscope with four channels, 70 MHz bandwidth, and 12-bit resolution, ideal for professional and educational applications. It offers a sampling rate of up to 1.25 GSa/s, 25 Mpts of memory, and an acquisition rate of up to 1,000,000 wfms/s in UltraAcquire mode, enabling precise capture of even rare signal anomalies. Equipped with a 7-inch touchscreen, intuitive controls, USB, LAN, and HDMI interfaces, and USB-C power, it offers ease of use and portability.
Description
RIGOL DHO804 is a modern and cost-effective digital oscilloscope that combines a compact design with high measurement precision. Equipped with four analog channels and a 70 MHz bandwidth, it ensures high-quality signal acquisition for both professional and educational applications. With its 12-bit resolution and low noise, the oscilloscope enables precise analysis of even very small signals, which is especially important when working with low-voltage circuits. The device offers a maximum sampling rate of 1.25 GSa/s in single-channel mode, ensuring accurate waveform representation. Acquisition memory reaches 25 Mpts, and the maximum waveform capture rate is up to 1,000,000 wfms/s in UltraAcquire mode, making it possible to capture rare and non-repetitive signal anomalies. Built-in search and navigation functions simplify waveform analysis and reduce debugging time.
The DHO804 features a 7-inch touchscreen display with a resolution of 1024×600, which, combined with intuitive Flex Knobs, provides convenient operation and quick access to key functions. Its digital phosphor display with 256-level intensity grading renders waveforms realistically and clearly, allowing users to quickly assess signal changes in real time. With USB Host & Device, LAN, and HDMI interfaces, the oscilloscope supports remote control, easy data transfer, and presentation of results, e.g., during meetings or training sessions. It also supports online updates, ensuring access to the latest features and long-term usability.
The lightweight and compact design makes the DHO804 space-saving on the workbench, while the option of USB-C power supply allows for field use, e.g., with a power bank. This makes it an ideal tool for engineers, students, service technicians, and hobbyists who need a powerful, precise, and user-friendly oscilloscope for everyday testing and measurement tasks.
Features
- Bandwidth: 70 MHz
- Analog channels: 4
- Vertical resolution: 12 bit (4096 quantization levels)
- Max. sampling rate: 1.25 GSa/s (1 channel), 625 MSa/s (2 channels), 312.5 MSa/s (4 channels)
- Acquisition memory: 25 Mpts (1 channel), 10 Mpts (all channels)
- Waveform capture rate: up to 1,000,000 wfms/s (UltraAcquire), 30,000 wfms/s (vector mode)
- Vertical sensitivity range: 500 μV/div – 10 V/div
- Display: 7″ touchscreen (1024×600)
- Waveform display: digital phosphor display, 256-level intensity grading
- Functions: waveform search, navigation, signal anomaly debugging
- Interfaces: USB Host & Device, LAN, HDMI
- Power supply: USB-C port (powerbank support)
- Design: compact, lightweight, VESA-compatible
- Updates: online update support
- Dimensions: 265.35 × 161.75 × 77.38 mm
- Weight: 1.78 kg
Kit contains
- Rigol DHO804
- 4 × probes
- USB cable
- Power cord
1194342
Data sheet
- Type of oscilloscope
- Digital
- Bandwidth
- 70 MHz
- Sampling rate
- 1.25 GSa/s
- Memory depth
- 25 Mpts
- Number of channels
- 4
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
