DC axial fan 0,6W 25x25x10 mm
ID: 1193653
5902186306585
zł23.99
Tax included
zł19.50 tax excl.
The SUNON 25x25x10 mm DC fan is a perfect solution for cooling small electronic devices, offering high rotational speed and reliable operation in a compact housing. Sunon MF25101V1-1000U-A99
Description
The 25x25x10 mm SUNON DC axial fan is a compact and efficient cooling solution, ideal for miniature electronic systems requiring reliable heat dissipation. The fan operates at a voltage of 6 to 13.8V, consuming 0.6W of power and a rated current of 50 mA. At a rotational speed of 14,000 rpm, it generates an air flow of 6.42 m³/h while maintaining a noise level of 26 dBA. The use of Vapo bearings ensures long service life and quiet operation. The fan is made of durable thermoplastic that meets ECE R-118 and UL94V-0 flammability standards, which guarantees safe use in various conditions. Thanks to the brushless DC motor with auto-restart function, the fan offers reliable operation, even in difficult operating conditions. It is equipped with two 0.15 m long and 28AWG wires, which facilitates its installation.
Properties
- Fan type: DC, axial
- Dimensions: 25x25x10 mm
- Operating voltage: 6-13.8V
- Power consumption: 0.6W
- Rated current: 50 mA
- Productivity: 6.42 m³/h
- Noise level: 26 dBA
- Rotational speed: 14000 rpm
- Static pressure: 6.86 mm H2O
- Bearing type: Vapo
- Insulation resistance: min. 10 MΩ
- Rotor material: thermoplastic
- Housing material: thermoplastic
- Insulation class: A
- Terminals: 2x 28AWG cable, length 0.15 m
- Operating temperature: -10...70°C
- Flammability class: ECE R-118, UL94V-0
- Fan motor: brushless DC
- Additional functions: autorestart
1193653
Data sheet
- Voltage
- 6 - 13,8 V
- Power
- 0,6 W
- Length
- 25 mm
- Width
- 25 mm
- Height
- 10
- Weight
- Other
- Noise level
- 26 dBA
- Air flow efficiency
- 6,42 m³/h
- Rated current
- 50 mA
- Fan type
- Axial
