zł68.62 tax excl.
Air quality sensor module based on the SGP40 system. It uses CMOSens technology by Sensirion and provides information on the concentration of volatile organic compounds (VOC). Adafruit 4829
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Air quality sensor module based on the SGP40 system. It uses Sensirion's CMOSens technology and provides indoor air quality information based on volatile organic compounds (VOC) with humidity compensation. Both the sensing element and the VOC algorithm are highly resistant to contaminating gases present in real-world applications, allowing long-term stability as well as low drift. It can work with systems with a working voltage of 3.3 V or 5 V, and communication is via the I2C interface (STEMMA QT connector) or SPI. It can be used to measure emissions from natural gas, cigarette smoke and emissions from construction work, decoration materials, furniture, household appliances, and then generate digital signals to start air treatment devices. The SGP40 VOC sensor is compact, making it easy to integrate with air handling units and air quality monitors. Full documentation with examples is available on the product page.
Features
- Measuring range: 0 to 1000 ppm
- VOC indicator: 0 to 500
- Response time: <10 s
- First measurement time: <60 s
- Support for humidity compensation
- Interface: I2C (address 0x59)
- Voltage: 3.3V or 5V
- STEMMA QT connector
Kit contains
- STEMMA QT SGP40 Air Quality module
- 6-pin straight male goldpin connector
Data sheet
- Interface
- I2C
- Type of sensor
- SGP40
- Power supply voltage
- 3,3 - 5 V
- Concentration measurement
- VOC
