ID: 1208036
4779051847143
zł1,682.47
Tax included

zł1,367.86 tax excl.

Industrial edge router for IoT systems, automation, energy applications and infrastructure requiring high connection availability; 2 independent 4G LTE Cat 4 modems with up to 150 Mbps download and 50 Mbps upload each; 3G up to 21/5.76 Mbps; 2G; 2 x Mini SIM and 2 x eSIM; independent SIM/eSIM switching for each modem; Failover and Load Balancing; dual-band WiFi 6 with MU-MIMO up to 2402 Mbps at 5 GHz and 576 Mbps at 2.4 GHz; up to 500 WiFi clients; 1 WAN port and 4 Gigabit Ethernet LAN ports; Docker; dual-core MediaTek 1.3 GHz processor; 1 GB DDR4 RAM; 8 GB eMMC; USB 2.0; digital input and output; Modbus TCP, DNP3, DLMS/COSEM, OPC UA, BACnet and MQTT; passive PoE 9-50 VDC; RutOS; Teltonika RMS; operating temperature from -40°C to 75°C. Teltonika RUTC42

24h
Available
Available quantity: 1

Description

Industrial edge router designed for automation systems, IoT, energy applications and infrastructure requiring high connection availability. Teltonika RUTC42 uses two independent 4G LTE Cat 4 modems, each supporting download speeds up to 150 Mbps and upload speeds up to 50 Mbps, as well as 3G and 2G networks. Two Mini SIM slots and two eSIMs enable independent SIM switching for each modem, supporting Failover and Load Balancing functions. The router provides dual-band WiFi 6 802.11b/g/n/ac/ax with MU-MIMO, speeds up to 2402 Mbps at 5 GHz and 576 Mbps at 2.4 GHz, support for up to 500 simultaneous clients and five Gigabit Ethernet ports: one WAN and four LAN ports.

A dual-core 1.3 GHz processor, 1 GB DDR4 RAM and 8 GB eMMC provide resources for local data processing, while Docker support enables custom containerized applications to run directly on the router. A USB 2.0 port and digital input and output expand integration capabilities with external equipment. RutOS provides routing, firewall, VLAN, VPN and industrial protocol support, while Teltonika RMS enables remote configuration and monitoring. A 9-50 VDC input range, passive PoE through LAN1 and an aluminium enclosure support use in industrial installations, monitoring systems, telemetry and environments requiring connection redundancy and local data processing.

Features

  • Cellular connectivity
    • 2 x 4G LTE Cat 4 cellular modem
    • Standards: 4G LTE Cat 4, 3G, 2G
    • 4G LTE speed: up to 150 Mbps download / 50 Mbps upload per modem
    • 3G speed: up to 21 Mbps download / 5.76 Mbps upload
    • 2G speed: up to 236.8 kbps download / 236.8 kbps upload
    • 3GPP: Release 9
    • Simultaneous operation of both modems
    • SMS and USSD support
    • Operator blocklist and allowlist
    • Band management and band lock
    • SIM PIN code management
    • Auto APN
    • Bridge and Passthrough modes
    • 4 x SMA connector for cellular antennas
  • SIM and eSIM
    • 2 x Mini SIM slot (2FF)
    • SIM voltage: 1.8 V / 3 V
    • External SIM holders
    • 2 x consumer-type eSIM
    • Up to 7 eSIM profiles
    • eSIM profile download and removal
    • Independent SIM/eSIM switching for each modem
    • Simultaneous operation of both physical SIM cards
    • Automatic switching criteria: weak signal, data limit, roaming and network issues
  • WiFi
    • Standard: IEEE 802.11b/g/n/ac/ax
    • Class: WiFi 6
    • Bands: 2.4 GHz and 5 GHz
    • MU-MIMO
    • Maximum speed at 5 GHz: 2402 Mbps
    • Maximum speed at 2.4 GHz: 576 Mbps
    • Maximum simultaneous connections: 500
    • WPA2-Enterprise
    • WPA2-PSK
    • WPA-EAP
    • WPA-PSK
    • WPA3-SAE
    • WPA3-EAP
    • OWE
    • AES-CCMP
    • TKIP
    • EAP-TLS with PKCS#12 certificates
    • 802.11w Protected Management Frames
    • 802.11s Wireless Mesh
    • 802.11r Fast Roaming
    • 802.11v BSS Transition Management
    • 802.11k Radio Resource Measurement
    • Relayd
    • SSID hiding
    • MAC address-based access control
    • MAC allowlist and blocklist
    • WiFi connection QR code generator
    • TravelMate
    • 3 x RP-SMA connector for WiFi antennas
  • Ethernet
    • 1 x WAN RJ45 10/100/1000 Mbps port
    • 4 x LAN RJ45 10/100/1000 Mbps ports
    • Total: 5 x Gigabit Ethernet ports
    • IEEE 802.3, IEEE 802.3u and IEEE 802.3az compliant
    • Auto MDI/MDIX
    • Port Mirroring
  • Edge Computing and Docker
    • Docker container support
    • Running custom applications and services directly on the router
    • Local data processing and storage
    • Cloud service integration
  • USB
    • 1 x USB Type-A port
    • Standard: USB 2.0
    • Samba Share
    • USB-to-Serial
    • External HDD support
    • Flash drive support
    • Additional modem support
    • Printer support
    • USB-Serial adapter support
    • Supported file systems: FAT, FAT32, exFAT, NTFS read-only, ext2, ext3, ext4
  • Inputs and outputs
    • 1 x digital input
    • Input logic low: 0-6 V
    • Input logic high: 8-50 V
    • 1 x digital open collector output
    • Maximum output parameters: 50 V / 300 mA
    • Input and output on the 4-pin power connector
    • Event support via Email, RMS and SMS
    • I/O Juggler
  • Industrial and IoT protocols
    • Modbus TCP: Client, Server
    • OPC UA: Client, Server
    • BACnet/IP: Router
    • BACnet RTU over USB
    • DNP3: Station, Outstation
    • DNP3 over TCP and USB
    • DLMS/COSEM: Client
    • DLMS/COSEM over TCP
    • MQTT
    • Modbus MQTT Gateway
    • Data to Server: HTTP(S), MQTT, Azure MQTT
    • Lua scripting support in Data to Server
    • Teltonika Networks Web API
  • Network and routing
    • Static routing
    • Dynamic routing: BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP
    • Policy Based Routing
    • Network Backup
    • Automatic WAN Failover
    • Load Balancing for multiple WAN connections
    • DHCP Server and DHCP Relay
    • QoS / Smart Queue Management
    • DDNS
    • DNS over HTTPS
    • Hotspot
    • Hotspot 2.0
    • SSHFS
    • VRF
    • Real-time network traffic monitoring
    • Port Mirroring
  • Security and VPN
    • Firewall
    • NAT, NAT-T, NAT64 and DMZ
    • Port- and tag-based VLAN
    • 802.1X
    • DDoS attack prevention
    • Port scan prevention
    • Mobile data quota control
    • Web filtering
    • Access control for SSH, WEB UI, CLI and Telnet
    • TACACS+
    • RADIUS
    • Certificate Manager
    • OpenVPN
    • IPsec with IKEv1 and IKEv2
    • WireGuard
    • ZeroTier
    • Tailscale
    • GRE
    • PPTP
    • L2TP and L2TPv3
    • SSTP
    • DMVPN
    • Tinc
    • Stunnel
  • Management and software
    • Operating system: RutOS based on OpenWrt
    • WEB UI over HTTP/HTTPS
    • Teltonika Remote Management System (RMS)
    • FOTA
    • SSH
    • SNMP
    • SNMP Trap
    • TR-069
    • JSON-RPC
    • MQTT Broker and MQTT Publisher
    • ThingWorx
    • Cumulocity
    • Azure IoT Hub
    • AWS IoT Core
    • Package Manager
    • BusyBox shell, Lua, C and C++
    • SDK for custom software development
    • Docker
  • Hardware
    • Processor: MediaTek Dual Core 1.3 GHz
    • RAM: 1 GB DDR4
    • Flash memory: 16 MB Serial NOR Flash
    • eMMC storage: 8 GB
  • Power supply
    • Power connector: industrial 4-pin DC connector
    • Input voltage: 9-50 VDC
    • Reverse polarity protection
    • Surge protection
    • Passive PoE through LAN1
    • Passive PoE: Mode B, 9-50 VDC
    • Passive PoE not compliant with IEEE 802.3af, IEEE 802.3at or IEEE 802.3bt
    • Idle power consumption: below 6 W
    • Maximum power consumption: below 24 W
  • Mechanical and environmental parameters
    • Housing: anodized aluminium
    • Dimensions: 130.4 x 42.6 x 103.4 mm
    • Weight: 452 g
    • Ingress protection rating: IP30
    • Operating temperature: from -40°C to 75°C
    • Operating humidity: from 10% to 90%, non-condensing
    • 5 x RJ45 10/100/1000 Mbps ports
    • 1 x USB Type-A port
    • 1 x 4-pin power connector
    • 4 x SMA connector for cellular antennas
    • 3 x RP-SMA connector for WiFi antennas
    • 1 x grounding screw
    • WAN, cellular network, signal strength, Ethernet, WiFi and power status LEDs
    • Reset button
    • DIN rail, wall or flat-surface mounting with an additional mounting kit

Kit includes

  • Teltonika RUTC42 router
  • 18 W power supply
  • 4 x SMA cellular antenna
  • 3 x dual-band WiFi antenna
  • 1.5 m Ethernet cable
  • SIM adapter kit
  • Quick Start Guide
1208036

Data sheet

Cellular Network Standard
4G LTE Cat 4 / 3G / 2G
WiFi module
Yes
Wi-Fi standard
802.11 b/g/n/ac/ax
WiFi Band
2,4 GHz / 5 GHz
Number of Ethernet Ports
5
Number of SIM Cards
2
eSIM
Yes
GNSS
No
PoE
Yes
VPN
Yes
Bluetooth module
No
RS232
None
RS485
None
DIN Rail Mounting
Yes
Power supply voltage
9 - 50 V DC
Tightness class
IP30
