Transceiver Breakout - 2.4GHz module with nRF24L01 chip and RP-SMA connector
ID: 201859
5906623416936
zł155.41
Tax included
zł126.35 tax excl.
2.4 GHz RF module with nRF24L01+ chip. The module has an RP-SMA connector with reverse polarity, allowing the connection of an external antenna. The system has a built-in 3.3 V stabilizer and IO lines with a tolerance of 5 V. SparkFun WRL-00705
Description
2.4 GHz RF module with nRF24L01+ chip from Nordic Semiconductor. The module has an RP-SMA connector with reverse polarity, allowing the connection of an external antenna. The system has a built-in 3.3 V stabilizer and IO lines with a tolerance of 5 V.
Features
- SMA connector for an external 2.4 GHz antenna
- Range up to 100 m 250 kbps
- Transmission speed from 250 kb/s to 2 Mb/s
- Automatic confirmation
- Auto Re-Trasmit
- Multiceiver - 6 data streams
- 32-byte FIFO
- Input pins with 5V tolerance
- Program selectable channel from 2400 MHz to 2525 MHz (125 channels selectable)
- Derived pins: VCC, CE, CSN, SCK, MOSI, MISO, IRQ, GND
- Built-in 3.3 V LDO stabilizer
- Power supply from 3.3 to 7 V
