A LoRa communication device designed for off-grid networks and long-range communication systems. The module is based on the nRF52840 microcontroller and the SX1262 radio chip operating in the 862–930 MHz band and offers additional Bluetooth 5.0 connectivity for smartphone communication. The device is equipped with an L76K GPS module supporting GPS, BeiDou, GLONASS, and QZSS systems, and a 1.3" OLED display for information presentation. A built-in 2000 mAh battery, USB-C charging, and the ability to be powered by a solar panel enable long-term operation in field applications and IoT systems. Seeed Studio 100030144

4 weeks
Awaiting delivery
Kamami is the official distributor of Seeed Studio modules and development kits. All products of this brand in our offer are original and come directly from the manufacturer.

Description

Wio Tracker L1 Pro is a compact and energy-efficient communication device based on LoRa technology, designed for field operation and communication networks operating outside traditional infrastructure coverage. The device comes in a durable, lightweight 3D-printed enclosure, making it ready to use immediately after unpacking without the need for additional assembly. This model features pre-installed Meshcore Bluetooth Companion firmware, enabling quick setup and easy integration with mobile applications and other devices using the Meshcore network.


MeshCore is a multi-platform system designed for secure text-based communication using LoRa radio hardware. This technology enables the creation of communication networks that operate independently of telecom infrastructure, making the device ideal for applications such as off-grid communication, emergency response, disaster recovery, outdoor activities, and security systems. Thanks to LoRa connectivity, the device can transmit data over long distances while maintaining extremely low power consumption.


The Wio Tracker L1 Pro is equipped with a powerful Nordic nRF52840 microcontroller featuring an ARM Cortex-M4 core with FPU, delivering high computing performance with low power consumption. The integrated SX1262 LoRa module supports the 862–930 MHz frequency range, enabling long-distance communication in many regions worldwide. The device also offers Bluetooth 5.0 connectivity, allowing easy connection to a smartphone or computer for configuration and message transmission.

The device also includes a built-in L76K GPS module supporting GPS, BeiDou, GLONASS, and QZSS satellite systems, enabling location tracking and the development of positioning and monitoring systems. Information can be displayed on a 1.3-inch OLED display with a resolution of 128 × 64 pixels, providing clear visibility even in outdoor conditions. With a 2000 mAh battery, USB Type-C charging, and the option to power the device from a solar panel, the system can operate for long periods without frequent recharging. The Wio Tracker L1 Pro is an ideal solution for users who need a mobile, independent communication system and a platform for building distributed IoT networks.

Features

  • Processor: Nordic nRF52840 ARM® Cortex®-M4 with FPU, clock speed up to 64 MHz
  • Built-in memory: 1 MB Flash
  • RAM: 256 kB
  • LoRa communication: Wio-SX1262 module
  • LoRa frequency range: 862–930 MHz
  • Bluetooth: Bluetooth 5.0
  • GPS module: L76K (supports GPS, BeiDou, GLONASS, QZSS)
  • Display: OLED 1.3 inch, 128 × 64 pixels
  • USB power input: Type-C 5 V / 1 A
  • Solar power interface: 2.0 mm 2-pin, 5 V / 1 A
  • Battery connector: JST 1.0 mm 2-pin
  • Battery voltage: 3.7 V / 1 A
  • Built-in battery: 2000 mAh
  • Enclosure: durable 3D-printed housing
  • Certifications: FCC, CE, RoHS, EUDOC, TELEC, UKDOC

Kit contains

  • Wio Tracker L1 with 1.3" OLED display, 3D-printed enclosure, and battery
  • LoRa antenna
