SIM7600G-H 4G LTE HAT Communication Module with GNSS for Jetson Nano - Seeed Studio 113990838
search
  • SIM7600G-H 4G LTE HAT Communication Module with GNSS for Jetson Nano - Seeed Studio 113990838
ID: 1200466
zł474.40
Tax included

zł385.69 tax excl.

The SIM7600G-H HAT module adds global 4G LTE connectivity and GNSS functions to the Jetson Nano, supporting data transmission, SMS, and voice calls. With UART, USB, and GPIO interfaces and support for AT Commands, it is suitable for IoT projects, remote monitoring systems, and mobile AI applications.

4 weeks
On request
Kamami is the official distributor of Seeed Studio modules and development kits. All products of this brand in our offer are original and come directly from the manufacturer.

Description

The SIM7600G-H module in HAT format expands the NVIDIA Jetson Nano developer kit with global 4G/3G/2G connectivity and GNSS functions (GPS, BeiDou, GLONASS, LBS). It supports LTE CAT 4 transmission with download speeds up to 150 Mb/s and upload speeds up to 50 Mb/s, while maintaining low power consumption. With an integrated SIM slot, USB interface, audio jack output, and support for communication protocols (HTTP, FTP, TCP, UDP, SMS, voice calls), the module is suitable for IoT solutions, remote video monitoring, and telemetry systems.

It also supports AT Commands, allowing full control of functionality from software. Built-in antenna connectors (LTE, AUX, GNSS) enable flexible adaptation to working conditions.

Properties

  • Communication standard: LTE CAT 4, 3G, 2G
  • LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28/B66
  • LTE-TDD: B34/B38/B39/B40/B41
  • UMTS/HSPA+: B1/B2/B4/B5/B6/B8/B19
  • GSM/GPRS/EDGE: 850/900/1800/1900 MHz
  • LTE: up to 150 Mb/s (DL), up to 50 Mb/s (UL)
  • HSPA+: up to 42 Mb/s (DL), up to 5.76 Mb/s (UL)
  • GNSS: GPS, BeiDou, GLONASS, LBS
  • Positioning accuracy: <2.5 m CEP
  • Tracking sensitivity: -159 dBm (GPS)
  • TTFF: <35 s (cold start), <1 s (warm start)
  • Additional functions: SMS (PDU/Text), voice calls (microphone + headphones), noise reduction, echo cancellation
  • GPIO 40-pin (Jetson Nano)
  • UART (detachable)
  • USB (AT Commands test, GPS data)
  • SIM slot (1.8/3 V)
  • Audio: 3.5 mm jack
  • Antenna connectors: LTE, AUX, GNSS
  • Power supply: 5 V (via GPIO or USB)
  • Configurable operating voltage: 3.3 V / 5 V (jumper)
  • Operating temperature: -30°C to 80°C
  • Dimensions: HAT format compatible with Jetson Nano

Set includes

  • 1 × SIM7600G-H 4G LTE HAT module for Jetson Nano
  • 1 × LTE antenna
  • 1 × external GNSS antenna (B)
  • 1 × USB adapter for Jetson Nano
  • 1 × screw set (2 pcs.)
