Cogswell Carrier - motherboard for NVIDIA Jetson TX1 / TX2 / TX2i
ID: 574862
zł8,999.00
Tax included
zł7,316.26 tax excl.
A base plate for NVIDIA Jetson TX1, Jetson TX2 or Jetson TX2i modules. Equipped with 5 Gigabit Ethernet ports, HDMI Video, USB 3.0, USB 2.0, USB OTG, Mini-PCIe / mSATA and two serial RS-232 ports. Connect Tech ASG007
Description
Cogswell Carrier from Connect Tech is a motherboard for NVIDIA Jetson TX1 , NVIDIA Jetson TX2 or NVIDIA Jetson TX2i modules . It is an ideal solution for use in Gigabit Ethernet applications. The product provides Gigabit Ethernet channels with built-in Power over Ethernet (PoE) power supply options, ideal for use with GigE Vision cameras.
The Cogswell board includes 5 Gigabit Ethernet ports. Four of these ports can be used for IEEE 802.3af (PoE) with 15.4 W power or two of these ports can be used for IEEE 802.3at (PoE +) 25.5 W power source. In addition, Cogswell Carrier provides HDMI Video, USB 3.0, USB 2.0, USB OTG, Mini-PCI / mSATA and two RS-232 serial ports.
Attention!
The kit does not contain NVIDIA Jetson TX1 / TX2 or TX2i modules . They should be purchased separately.
properties
- Compatible with NVIDIA Jetson TX1 , NVIDIA Jetson TX2 , and NVIDIA Jetson TX2i
- 5 x Gigabit Ethernet ports
- 4 x Gigabit Ethernet PSE 4 x IEEE 802.3af (POE) port
- 2 x IEEE 802.3at (POE +) 25.5 W PSE Gigabit Ethernet
- HDMI
- USB 2.0, USB 2.0 jack for miniPCIe, USB 3.0, USB OTG
- MicroSD card slot, full mSATA socket
- 2 x RS-232
- I2C Channel 1 @ 3.3V IO
- CAN port 2.0b
- GPIO 4 bits 3.3 V
- miniPCIe Slot with PCIe and USB
- LEDs - GbE LEDs, PSU PGOOD, RESET #_OUT
- Power supply: +12 V DC
- Working temperature -40 ~ 85 ° C
- Dimensions: 178 x 147.5 mm
Arrangement of elements on the board and description of outputs
574862
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
