MCC USB-1608GX-2AO (6069-410-011)
ID: 1178649
zł4,299.00
Tax included
zł3,495.12 tax excl.
USB-based DAQ device with 16 single-ended or 8 differential analog inputs, two analog outputs, 8 digital I/O, and two counter inputs and one output. It offers 16-bit resolution and a sampling rate of 500 kS/s. Digilent 6069-410-011
Description
The Measurement Computing USB-1608GX-2AO are USB-based, high-speed, multifunction DAQ devices. Each device offers 16 SE/8 DIFF analog inputs, eight digital I/O channels, two counter inputs, and one timer output. The USB-1608GX-2AO features two, 16-bit analog output channels with DAC rates up to 500 kS/s.These devices are USB-powered and require no external power.
These devices provide 16-bit analog inputs that are software-selectable as eight DIFF or 16 SE inputs. They also support input ranges of ±10 V, ±5 V, ±2 V, and ±1 V that are software-selectable per channel. Both devices feature a maximum 500 kS/s sample rate.
The USB-1608GX-2AO has two 16-bit analog outputs that can be updated at a rate of 250 kS/s per channel; one output can be updated at a rate of 500 kS/s. The output range is fixed at ±10 V.
USB-1608G Series devices have an external digital trigger input. The trigger mode is software-selectable for edge- or level-sensitive mode. Users can configure edge-sensitive mode for either rising or falling edge. In level-sensitive mode, the trigger can be configured for either high or low level. The default setting at power up is edge sensitive, rising edge.
Eight bidirectional digital I/O lines are individually configurable for input or output. The DIO terminals can detect the state of any TTL-level input. Users can configure for pull-up (+5 V) or pull-down (0 V) with an onboard jumper.
Two 32-bit event counters are provided to count TTL pulses. The counters accept inputs of up to 20 MHz.
A PWM timer output generates a pulse output with a programmable frequency in the range of 0.0149 Hz to 32 MHz. The timer output parameters are software selectable.
Software support includes DAQami, an optional out-of-the-box application for data logging, visualization, and signal generation. Data can be viewed in real-time or post-acquisition on user-configurable displays. Drivers are included for the most popular applications and programming languages including Visual C++®, Visual C#®, Visual Basic®.NET, DASYLab®, LabVIEW™, MATLAB®, Linux®, and Python™.
Features
- 16 SE/8 DIFF analog inputs
- 16-bit resolution
- 500 kS/s sample rate
- ±10 V, ±5 V, ±2 V, ±1 V input ranges
- Two analog outputs
- Eight digital I/O
- Two counter inputs
- One timer output
- No external power required. USB cable is included
Kit contains
- MCC USB-1608GX-2AO
- USB cable
