Juntek KG110F - Li-Fe battery monitor
ID: 1186079
5906623452361
zł339.11
Tax included
zł275.70 tax excl.
Li-Fe battery monitor that can measure voltage, current, power during charging and discharging, and watt-hours consumed and run time. The user can use a mobile application and a computer to control the measuring module. Juntek KG110F
Description
The KG-F series Li-Fe battery monitor is a device that can measure various parameters such as voltage, current, power during charging and discharging, as well as watt-hours consumed and operating time. It allows you to configure parameters and has many built-in protection functions, such as overvoltage protection, undervoltage protection, overcurrent protection, overvoltage protection, and overheating protection.
The meter can automatically identify the direction of current flow and monitor battery capacity in real time, and display the measured data on the color LCD screen. Allows you to display and export voltage and current curves. At the same time, the user can use the mobile application and computer to control the measurement module, and the firmware can be updated to access all new functionalities.
Features
- Sampling method: shunt
- Voltage measurement range (external power supply): 0 to 120 V
- Voltage measurement range (internal power supply): 10 to 120 V
- Voltage resolution: 0.01V
- Current measurement range: 0 to 100 A
- Current resolution: 0.01 A
- Temperature measurement range: -20-120℃
- Capacity display range: 0% ~ 100%
- Power measurement range: 0 ~ 72KW
- Power Resolution: 0.01W
- AH measurement range: 0 ~ 9999.99AH
- Capacity resolution: 0.001AH
- Watt-hour measurement range: 0 to 9999.99 kWh
- Watt-hour accuracy: 0.001WH
- Timing range: 0 to 999:59:59S
- Time resolution: 1 s
- Bluetooth communication distance: 10 m
- Voltage accuracy: ±1%+2 digits
- Current accuracy: ±1%+0.02A, ±1%+0.1A ±1%+0.1A
- Sampling rate: 1 Hz
- Power consumption of the measuring module: 0.4 W
- Display module power consumption: 0.5 W
- Over-power protection: 0-99999.99 W
- Overcurrent protection: 100A
- Overvoltage protection: 0 to 120V
- External overheat protection: 0 to 120℃
- Protection recovery time: 0 to 99 s
- Standby time: 0-60s/Auto (I=0 and time>20s)
- Delay time setting: 0 to 99S
- Communication address: P01-P99, P00 is the broadcast address
Kit contains
- Measurement module
- Module with display
- Sampler
- 3m communication cable
- Temperature sensor
- 4-pin connection cable
- 3-pin connection cable
- Screw connection
- Instruction
