PCIe-to-M.2 board (C) for Raspberry Pi 5 - Waveshare 26785
ID: 1190048
5906623486748
zł33.16
Tax included
zł26.96 tax excl.
PCIe to M.2 adapter designed to work with the Raspberry Pi 5 minicomputer. It allows you to connect an NVMe SSD with an M.2 connector to the base board via a PCIe connector. Waveshare PCIe TO M.2 Board (C)
Description
This PCIe to M.2 adapter is designed to work with the Raspberry Pi 5 minicomputer. It allows the connection of an NVMe SSD with an M.2 interface to the Raspberry Pi via a PCIe slot, providing faster read/write speeds and enhanced performance. The adapter is compatible with various M.2 SSD sizes and features a built-in LED to indicate power and data transmission. This is an ideal solution for Raspberry Pi 5 projects requiring fast data storage and retrieval using SSD drives.
Features
- Connector 1: M.2
- Connector 2: PCIe
- Supports NVMe protocol
- Designed for Raspberry Pi 5
- Compatible with PCIe ×1 Gen2 or Gen3
- Supports M.2 SSD sizes: 2230, 2242, 2260, 2280
- Includes an acrylic case
- Dimensions: 87 x 37.5 mm
Kit contains
- PCIe to M.2 Adapter (C)
- Transparent acrylic mounting plate
- PH2.0 3-pin cable (~5 cm)
- 50 mm PCIe cable
- Standoff set
1190048
Data sheet
- Compatible with
- Raspberry Pi 5
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
