This DIY microdrone kit is based on the Seeed Studio XIAO ESP32-S3 module, which features a dual-core 240MHz Xtensa LX7 processor and 2.4GHz Wi-Fi connectivity. Controllable via the ESP-Drone app via Wi-Fi or ESP-NOW, the drone offers ranges of up to 50m and 200m, respectively, and low communication latency of 7-25ms. A quad-layer flight controller with an MPU6050 sensor and auto-leveling function makes learning to fly easy, while four 70,000rpm coreless motors ensure dynamic flight. Seeed Studio 114993694

4 weeks
On request
Kamami is the official distributor of Seeed Studio modules and development kits. All products of this brand in our offer are original and come directly from the manufacturer.

Description

ESP-FLY DIY Kit is a compact self-assembly micro drone kit based on the Seeed Studio XIAO ESP32-S3 module. The kit is designed for STEM education, programming learning, and hobbyists interested in electronics, robotics, and drone technology. The product is supplied as a DIY kit and therefore requires self-assembly and soldering before use. This allows users not only to build their own drone but also to gain a deeper understanding of electronic circuits and flight control systems. At the core of the design is the powerful XIAO ESP32-S3 microcontroller, featuring a dual-core Xtensa LX7 processor running at up to 240 MHz and 2.4 GHz Wi-Fi connectivity. The drone offers two control methods – via the ESP-Drone application over Wi-Fi or through ESP-NOW technology using a compatible radio controller. In Wi-Fi mode, communication latency is as low as approximately 7–25 ms, ensuring smooth and responsive flight control. Flight stability is provided by a dedicated four-layer flight controller board equipped with an MPU6050 six-axis sensor. Thanks to the automatic leveling function in Angle mode, even beginners can quickly learn the basics of piloting.


The propulsion system is based on four coreless motors capable of reaching speeds of up to 70,000 RPM, providing excellent maneuverability and rapid response to control inputs. Compact dimensions of 67 × 67 × 31 mm and a takeoff weight of only 25 g make the drone ideal for safe indoor flights. Power is supplied by a 3.7 V 250 mAh LiPo battery, providing approximately 5 minutes of flight time per charge. Charging is conveniently performed via the USB-C port available on the XIAO ESP32-S3 module. The maximum control range is approximately 50 m when using a smartphone and up to 200 m when using ESP-NOW communication. The project's open architecture enables users to develop their own software, experiment with control algorithms, and integrate additional features. ESP-FLY is an excellent educational platform for students, makers, and anyone wishing to gain practical experience in building and programming unmanned aerial vehicles.

Features

  • Controller module: XIAO ESP32-S3
  • Processor: Xtensa® 32-bit LX7, dual-core, up to 240 MHz
  • IMU sensor: MPU6050
  • Motors: 615 coreless motors (70,000 RPM)
  • Propellers: 30 mm (CW and CCW)
  • Wireless connectivity: 2.4 GHz Wi-Fi (AP mode) and ESP-NOW
  • Control range via smartphone: approximately 50 m
  • Control range via ESP-NOW and controller: approximately 200 m
  • Dedicated 4-layer flight controller PCB
  • Automatic flight leveling in Angle mode
  • Control via the ESP-Drone application over Wi-Fi
  • Control via a controller using ESP-NOW
  • Wi-Fi transmission latency: approximately 7–25 ms
  • Designed for STEM education, electronics learning, and programming
  • Requires self-assembly and soldering
  • Battery: LiPo 3.7 V 250 mAh 25C
  • Flight time: approximately 5 minutes
  • Charging: USB-C (via the XIAO module)
  • Takeoff weight: 25 g (including battery)
  • Dimensions: 67 × 67 × 31 mm

Kit contains

  • Seeed Studio XIAO ESP32-S3 module
  • 2.4 GHz antenna for XIAO ESP32-S3
  • IMU / motor driver module
  • 2 × 24 AWG red/black wires for connecting battery power to the XIAO module
  • 4 × 6 × 15 mm coreless motors (2 CW and 2 CCW with pre-soldered wires)
  • 8 × 30 mm three-blade propellers (4 CW and 4 CCW)
  • 1S 3.7 V 250 mAh LiPo battery
  • Set of 3D-printed parts: frame, standard top cover, and optional FPV canopy
  • "ESP-FLY" sticker
  • Cable tie for battery mounting
  • 4 × Enameled wires for landing gear construction
