Sels PCID15ZPK - cylindrical inductive sensor, PNP, 15mm
ID: 1205405
zł160.37
Tax included
zł130.38 tax excl.
The M30 inductive sensor is designed for non-contact detection of metal objects in industrial automation systems. It offers a detection range of up to 15 mm and operates at voltages from 10 to 30 V DC, ensuring broad compatibility with control systems. A PNP NO output and a standard 4-pin M12 connector enable quick and easy installation. See PCID15ZPK.
Description
M30 inductive sensor is a device designed for non-contact detection of metal objects in industrial applications and automation systems. Thanks to its robust construction made of nickel-plated brass, the sensor offers high resistance to mechanical damage and harsh environmental conditions. This model provides a sensing range of up to 15 mm, enabling reliable detection even at greater working distances. The sensor operates with a 10 to 30 V DC power supply, ensuring wide compatibility with control systems.
The device uses a PNP output with NO (normally open) function, meaning the output signal is activated when an object is detected. Thanks to the standard M12 4-pin connector, installation is quick and convenient, and configuration does not require specialized tools. With an operating frequency of 100 Hz, the sensor ensures stable and fast detection in dynamic production processes. The compact, cylindrical design allows easy integration into various automation systems. The sensor is suitable for applications such as production lines, transport systems, industrial machinery, and metal object presence detection systems.
Features
- Type: inductive sensor
- Housing type: cylindrical
- Housing size: M30
- Length: 92 mm
- Housing material: nickel-plated brass
- Face type: non-flush
- Sensing range: 15 mm
- Supply voltage: 10 to 30 V DC
- Polarity: PNP
- Output function: NO
- Connection: 3-wire
- Electrical connection: M12 4-pin
- Load current: 200 mA
- Operating frequency: 100 Hz
- Protection rating: IP67
- Operating temperature: -25 to +70 °C
- Indicator: LED
