RS232/RS485-WiFi converter that provides easy communication between the RS232 or RS485 interface and the WiFi wireless network. Supports the Modbus RTU protocol

24h
Available
Available quantity: 13
Kamami is the official distributor of USR converters. All products of this brand in our offer are original and come directly from the manufacturer.

Description

Industrial RS232/RS485 - WiFi converter that provides easy communication between the RS232 or RS485 interface and a wireless WiFi network. It supports popular internet protocols including IP, TCP, UDP, DHCP, DNS, HTTPS, ARP and ICMP. The user can also configure the module using AT commands using the RS232 protocol available on the DB9 or RS485 connector led out on the screw connector. The device provides stable communication, has built-in ESD protection and overvoltage and overload protection. The converter will be used in industry, agriculture or measurement systems.

Features

  • Ethernet port: 1 x WAN/LAN
  • Rx/TX buffer: max. 16 kb
  • Electromagnetic isolation 2KV
  • Network protocol: IP, TCP, UDP, DHCP, DNS, HTTPS, ARP, ICMP
  • Speeds: 10/100Mbps, MDI/MDIX
  • WiFi 802.11b/g/n
  • Frequency range: 2.412GHz-2.484GHz
  • Transmit power:
    • 802.11b: +19dBm(Max)
    • 802.11g: +18dbm (max)
    • 802.11n:+17dbm(Max)
  • Reception sensitivity
    • 802.11b: -89dBm
    • 802.11g: -81dBm
  • 802.11n: -73dBm
  • Interface
    • RS232: 300 to 460.8kbps
    • RS485: 300d 230.4kbps
  • Network Mode : Station/AP/AP+Station
  • Security: WEP/WPA-PSK/WPA2-PSK
  • Encryption: WEP64/WEP128/TKIP/AES
  • Client https, Modbus TCP<=>Modbus RTU
  • Configuration: Web sever + AT commands
  • Input voltage: DC 5 to 36V
  • Working temperature: -40℃ to 85℃
  • Dimensions: 86 x 82.5 x 25mm

Kit contains

  • USR-W610 Converter
  • Power supply
  • DB9 cable
  • Antenna
