Voltage Regulator Module 3.3V Step-Down 100mA D45V1E1F3
ID: 1196560
5902186320963
zł21.21
Tax included
zł17.24 tax excl.
An efficient step-down converter that reduces the input voltage to 3.3 V at a maximum current of 100 mA, offering high efficiency thanks to its low quiescent current (<20 μA). It supports input voltages from 3.3 V to 65 V, has short circuit and overheating protection, making it a reliable and energy-efficient solution. Pololu 5362
Description
The D45V1Ex module is a high-efficiency buck (step-down) voltage regulator that lowers the input voltage to 3.3 V with a maximum output current of 100 mA. It is a switching regulator (SMPS) characterized by an extremely low quiescent current (below 20 μA), ensuring high efficiency even under light loads. This makes it more energy-efficient than traditional linear regulators. The regulator supports an input voltage range of 3.3 V to 65 V, with the minimum voltage depending on the voltage drop at a given load. The module is equipped with short-circuit and over-temperature protection, ensuring high reliability. Its compact size facilitates integration into various electronic projects.
Pinout Description
- VIN - Power input
- GND - Ground
- VOUT - Output
Features
- Input voltage: 3.3 V to 65 V
- Output voltage: 3.3 V ±4%
- Maximum output current: 100 mA
- Low quiescent current: < 20 μA
- High efficiency even at low loads
- Short-circuit and over-temperature protection
- Dimensions: 7.6 x 12.7 x 4 mm
- Weight: 0.4 g
Regulator Parameters
1196560
Data sheet
- Output voltage
- 3,3 V
- Output current
- 100 mA
- Converter type
- Step-down
- Supply voltage min
- 3,3 V
- Supply voltages max
- 65 V
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
