60W Adjustable DC-DC Buck Converter - DC-DC Step-Down Converter 5V 18A
ID: 1185016
5906623407576
zł43.96
Tax included
zł35.74 tax excl.
Step-down DC-DC converter module that converts a 12 V or 11.1 V output voltage (e.g. from a lithium battery) to a voltage in the range of 1.8 V to 5.1 V. It has a power output of up to 60 W, and with an output current of up to 18 A, the module can be used to power a 5 m WS2812 RGB LED strip. DFRobot DFR1025
Description
Step-down DC-DC converter module that converts a 12 V or 11.1 V output voltage (e.g. from a lithium battery) to a voltage in the range of 1.8 V to 5.1 V. It has a power output of up to 60 W, and with an output current of up to 18 A, the module can be used to power a 5 m WS2812 RGB LED strip or any other device requiring low voltage and high current consumption. In addition, the converter has built-in protection features such as short-circuit protection, overcurrent protection and overheating protection to ensure stable operation. Full documentation is available on the product page.
Features
- Input voltage: 9 V to 15 V
- Output voltage: 1.8 V to 5.1 V
- Output current: 18 A
- Output power: 60 W
- Passive power dissipation
- Conversion efficiency: 92%
- Dimensions: 52 x 37 mm
Kit contains
- Module 60W Adjustable DC-DC Buck Converter
- 2 x 2-pin screw connector
- Aluminium heat sink
1185016
Data sheet
- Output voltage
- 1,8 V - 5,1 V
- Output current
- 18 A
- Converter type
- Step-down
- Supply voltage min
- 9 V
- Supply voltages max
- 15 V
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
