DC 180W 36V 5.1A power supply
ID: 1184678
5906623449675
zł277.72
Tax included
zł225.79 tax excl.
A power supply based on a DC-DC converter with a current capacity of up to 5.1 A. The input voltage can range from 5 V to 30 V, while the output voltage is adjustable from 0 V to 36 V. XY3605
Description
A power supply based on a DC-DC converter. The input voltage can range from 5 V to 30 V, while the output voltage is adjustable from 0 V to 36 V. The power supply is equipped with a memory to store settings. This allows the user to save preferred parameters and easily restore them in the future. There is a 1.14-inch IPS LCD display that allows the user to conveniently monitor the power supply's settings and parameters. One important feature is its high efficiency of 95%.
The power supply is housed in an aluminium case, which ensures not only an attractive appearance but also excellent heat dissipation. In addition, it is equipped with a potentiometer that allows precise control of the output voltage. To ensure safe use, the power supply has overvoltage, overload, overheating and under-voltage protection features. These features protect both the power supply and connected devices from damage. The power supply is equipped with an IR remote control, which allows remote control from a distance. The power supply is compact in size, making it easy to carry and ideal for use in a variety of locations.
Features
- Input voltage: 5 V to 30 V
- Output voltage: 0 V to 36 V
- Output current: up to 5.1 A
- Output power: 180 W
- Memory for storing settings
- Display: LCD IPS 1.14"
- Efficiency: 95%
- Aluminium housing
- Potentiometer for control
- Protection against overvoltage, overload, overheating, undervoltage
- IR remote control
- DC input connector: 6 V to 30 V
- USB type C input with PD 20 V trigger
- External NTC temperature sensor
- Dimensions: 77 x 66 x 29 mm
Kit contains
- DC 180W 36V 5.1A power supply unit with WiFi communication
- Crocodile cables
- Temperature sensor
1184678
Data sheet
- Output voltage
- 0 - 35 V
- Output current
- 5A
- Converter type
- Step-down
- Supply voltage min
- 5 V
- Supply voltages max
- 30 V
