UT139B - Universal multimeter by Uni-T
ID: 233301
5901436796725
zł180.37
Tax included
zł146.64 tax excl.
Universal multimeter allows you to measure AC and DC voltage, AC and DC current and resistance. Equipped with diode test and NCV test. Uni-T UT139A
Description
Universal multimeter allows you to measure AC and DC voltage, AC and DC current and resistance. Equipped with diode test and NCV test.
| 1. Case | 4. Range switch |
| 2. LCD | 5. Input terminal |
| 3/4/7. Function buttons |
CAT III 600V digital multimeter designed for electricians. NCV function can effectively check the electrical condition by measuring the strength of the electromagnetic field.
Features
- Parameter measurement
- DC Voltage (V) 20mV / 200mV / 2V / 20V / 200V / 600V ± (0.5% + 2)
- AC voltage (V) 20mV / 200mV / 2V / 20V / 200V / 600V ± (1% + 3)
- DC current (A) 200μA / 2mA / 20mA / 200mA / 2A / 10 A ± (0.7% + 2)
- AC current (A) 200μA / 2mA / 20mA / 200mA / 2A / 10A ± (1% + 3)
- Resistance (Ω) 200Ω / 2kΩ / 20kΩ / 200kΩ / 2MΩ / 20MΩ ± (1% + 2)
- Capacity (F) 99.99mF ± (4% + 5)
- Frequency (Hz) 10 Hz ~ 10 MHz ± (0.1% + 4)
- Functionalities
- Display with a maximum reading of 2000
- Automatic range
- True RMS
- Bandwidth (Hz) 45 Hz to 400 Hz
- NCV test
- Continuity test
- Diode test
- General parameters
- Power supply: 2 x 1.5 V battery (R6)
- Display dimensions: 58 x 36 mm
- Color: Red-gray
- Dimensions: 170 x 80 x 48 mm
- Weight 354 g
Kit contains
- Universal multimeter Uni-T UT139A
- Test leads
- Battery
- Instruction
233301
Data sheet
- Zakres pomiarowy napięcia DC
- 400 mV/4 V/40 V/400 V/600 V
- Zakres pomiarowy napięcia AC
- 4 V/40 V/400 V/600 V
- Zakres pomiarowy natężenia DC
- 200μA/2mA/20mA/200mA/10A
- Zakres pomiarowy natężenia AC
- 600μA/6000μA/60mA/600mA/10A
- Zakres pomiarowy rezystancji
- 200Ω/2KΩ/20KΩ/200KΩ/2MΩ/20MΩ
- Zakres pomiarowy pojemności
- Brak
- Zakres pomiarowy częstotliwości
- Brak
- Pomiar temperatury
- Nie
- Regulacja zakresu pomiarowego
- Automatyczna
- True RMS
- Tak
- Funkcja Hold
- Nie
- Tester ciągłości obwodu
- Akustyczyny
- Tester diod
- Tak
- Pomiar hFE tranzystorów
- Nie
- Buzzer
- Tak
- Wskaźnik rozładowanej baterii
- Nie
- Automatyczny wyłącznik
- Nie
- Podświetlenie wyświetlacza
- Tak
- Battery type
- AA
- Length
- 170 mm
- Width
- 80 mm
- Thickness
- 48 mm
- Weight
- 353g
Manufacturer Lechpol Electronics Leszek Spółka komandytowa Garwolińska 1 08-400 Miętne Poland sprzedaz@lechpol.pl
Responsible person Lechpol Electronics Leszek Spółka komandytowa Garwolińska 1 08-400 Miętne Poland sprzedaz@lechpol.pl
