Arduino Nano Matter - ABX00112
ID: 1195431
7630049204867
zł89.90
Tax included
zł73.09 tax excl.
Arduino Nano Matter is a compact IoT board supporting the Matter and BLE protocols. Perfect for smart home and automation projects. Arduino ABX00112
Description
Arduino Nano Matter is a modern development board designed specifically for IoT and smart home projects. Equipped with advanced communication modules, it supports the Matter protocol—a universal standard enabling seamless integration and interoperability across various smart home platforms. Thanks to its compact size and extensive functionality, Arduino Nano Matter is a perfect solution for both hobbyists and professional engineers.
The board features the Silicon Labs MGM240S chip with an ARM Cortex-M33 processor and supports Bluetooth LE 5.3, Bluetooth Mesh, ZigBee, and Thread communication. It boasts low power consumption, extensive cryptographic functions, and an AI/ML accelerator. With a wide range of communication interfaces (ADC, I2C, SPI, UART, PWM, GPIO), it is specifically tailored for home and building automation networks.
Arduino Nano Matter supports the latest wireless communication standards, including Thread and Bluetooth Low Energy (BLE), ensuring easy integration with existing IoT networks. With Matter protocol support, the device can communicate with other Matter-compatible devices regardless of the manufacturer. The module is compatible with popular smart home ecosystems such as Google Home, Alexa, and Apple Home. Its compatibility with the Arduino platform provides access to a wide range of libraries and examples, enabling quick and efficient code development.
Arduino Nano Matter combines advanced technology with ease of use. Whether you're working on a DIY project or developing a professional IoT system, Arduino Nano Matter delivers reliability, performance, and flexibility.
Features
- Microcontroller: MGM240SD22VNA (32-bit Arm® Cortex®-M33 with DSP instructions and FPU)
- Connectivity: 802.15.4 (Thread), Bluetooth® Low Energy 5.3, Bluetooth® Mesh
- Matter protocol support for smart home integration
- Memory: 1536 kB Flash, 256 kB RAM
- USB-C connector
- Debugging via USB
- Communication interfaces: 2 x UART, 2 x I2C, 2 x SPI
- Digital I/O: 22
- Analog inputs: 20 (12-bit resolution)
- DAC: 4 (8-12 bit resolution)
- PWM pins: 22 (up to 5 simultaneously)
- External interrupts available on all digital pins
- RGB LED
- User button
- Operating voltage: 3.3 V
- Input voltage (VIN): 5 V
- Clock frequency: 78 MHz
- Built-in 2.4 GHz antenna
- Physical Dimensions: 18 x 45 mm
- Operating Temperature: -40 °C to +85 °C
- Security: Secure Vault™ High
1195431
Data sheet
- Microcontroller
- Core
- Cortex-M33
- Frequency
- Flash memory
- 1536 kB
- RAM
- 256kB
- EEPROM memory
- none
- Number of digital pins
- 22
- Number of PWM channels
- 22
- Ilość wejść analogowych
- ADC
- 1x 12bit
- DAC
- 4x 12 bit
- CAN
- none
- USB
- 1
- Ethernet
- none
- WiFi/BT module
- No
- Bluetooth module
- Yes
- GSM/GPRS module
- No
- Logic voltage
- 3,3 V
- MicroSD slot
- No
- Supply voltage min
- 6 V
- Supply voltages max
- 21 V
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
