Starter kit with micro:bit v2. Micro:bit v2 is an educational module with a 32-bit ARM Cortex-M4 processor designed for the youngest in order to interest them in computer engineering. On the board with dimensions of 52 x 43 mm there are, among others accelerometer, magnetometer, temperature sensor, LED matrix, touch button, as well as Bluetooth and USB connectivity. The module can be programmed by e.g. by the popular MakeCode editor. The manufacturer also provides a mobile application, available for Android and iOS phones, with which you can send the code to the device via Bluetooth connectivity. The set includes a short microUSB-USB cable, a basket for two AAA batteries, and two AAA batteries.
A user guide is available on the product page.
Comparison micro:bit and micro:bit v2
| micro:bit v1.5 | micro:bit v2 | |
| CPU | ARM Cortex-M0 | ARM Cortex-M4 |
| Flash | 256 kB | 512 kB |
| RAM | 16 kB | 128 kB |
| LED | Matrix 5x5 (red) | Matrix 5x5 (red) |
| Buttons | 2 | 2 + touch |
| Connectivity | 2,4 GHz micro:bit radio Bluetooth 4.0, BLE |
2,4 GHz micro:bit radio |
| Sensors and peripherals |
light |
light |
| Connectors | 25 pin 4 GPIO, PWM, I2C, SPI and power supply 3 ring connectors |
25 pin 4 GPIO, PWM, I2C, SPI and power supply 3 ring connectors |
| Power supply | 5 V microUSB 3 V edge connector |
5 V microUSB |
